4 SETPOINTS
PATH: SETPOINTS MMM S3: PROCESS M PROGRAMMABLE INPUTS
The first five messages are repeated for all ten interlock outputs.
NOTE
INTERLOCK INPUT 1:
NOT USED
MESSAGE
STARTUP OVERRIDE
MESSAGE
DELAY: 0 s
RUNNING OVERRIDE
MESSAGE
DELAY: 0 s
OPERATION:
MESSAGE
INTERLOCK STOP
INSTANTANEOUS ALARM:
MESSAGE
DISABLE
IL1 SWITCH TYPE:
MESSAGE
N.O.
LOCAL ISOLATOR:
MESSAGE
DISABLE
AUTO PERMISSIVE
MESSAGE
INDICATION: MANUAL
AUTO MODE =
MESSAGE
SERIAL
GE Power Management
Range: NOT USED, PROCESS INTERLOCK A to PROCESS
INTERLOCK J, PLANT INTERLOCK, LOCKOUT RESET,
SETPOINT ACCESS, AUTO PERMISSIVE, AUTO START A,
AUTO START B, RESET EMERGENCY STOP TRIP, RESET
UNDERCURRENT TRIP, TWO WIRE CONTROL, TEST
SWITCH, REMOTE
SELECT, INTERLOCK COUNTER, AUX RELAY 1 INHIBIT,
WYE-DELTA 1M CONTACT, WYE-DELTA 2S CONTACT, U/V
RESTART INHIBIT, AUTOTRANS 2S CONTACT, STOP A,
STOP B, REMOTE RESET, MOTOR SELECTOR A/B, DUTY
SELECT MANUAL/AUTO, BYPASS CONTACT
Note that interlock input functions are active when the applicable switch
input is closed and energized. See the following page for explanation of
the range options.
Range: 0 to 3600 seconds or OFF; Step: 1 second
See PROCESS INTERLOCK A.
Range: 0 to 3600 seconds or OFF; Step: 1 second
See PROCESS INTERLOCK A.
Range: INTERLOCK STOP, LATCHED TRIP
See PROCESS INTERLOCK A.
Range: ENABLE, DISABLE
See PROCESS INTERLOCK A.
Range: N.O., N.C.
This setpoint allows the user to configure the type of switch used for the
programmable switch inputs as normally open (N.O.) or normally closed
(N.C.). When set to N.O. (factory default), if the switch input is closed, it is
in the 'healthy' position; if the switch is open, it is in the 'unhealthy'
position. When set to N.C., if the switch input is open, it is in the 'healthy'
position; if it is closed, it is in the 'unhealthy' position.
Range: ENABLE, DISABLE
The Local Isolator switch input can be enabled or disabled using this
Setpoint. When set to ENABLE a Local Isolator Trip will occur whenever
the Local Isolator switch input is open. The trip will automatically reset
when the switch input is closed.
Range: MANUAL, AUTO
Range: SERIAL, HARD-WIRED
