4 SETPOINTS
TRANSFER TIME:
MESSAGE
10 s
HIGH SPEED START
MESSAGE
BLOCK: DISABLE
RAMP UP TIME:
MESSAGE
5 s
RAMP DOWN TIME:
MESSAGE
5 s
STAGE ONE SHORTING
MESSAGE
TIME: 5 s
CONTACTOR SEQUENCE:
MESSAGE
1S-2S
CHANGE OVER TIME:
MESSAGE
5 s
STARTS PER HOUR:
MESSAGE
5
GE Power Management
Range: 1 to 125 seconds; Step: 1 second
Appears only if STARTER TYPE is set as FV REVERSING or TWO SPEED. With
two-speed starters, this delay is required when the motor is switched
from high speed (Contactor B) to low speed (Contactor A). The delay
starts when Contactor B drops out. With a reversing starter, this delay
occurs when switching from forward (Contactor A) to reverse (Contactor
B) and from reverse to forward.
Range: ENABLE, DISABLE
Appears only if STARTER TYPE is selected as TWO SPEED. When disabled,
the MM3 allows the motor to be started directly to high speed. When
enabled, the motor must be started in low speed before switching to high
speed.
Range: 1 to 125 seconds; Step: 1 second
Appears only if STARTER TYPE is selected as INVERTER. See the description
of the Inverter starter type for details on functionality.
Range: 1 to 125 seconds; Step: 1 second
Appears only if STARTER TYPE is selected as INVERTER. See the description
of the Inverter starter type for details on functionality.
Range: 1 to 125 seconds; Step: 1 second
Appears only if STARTER TYPE is selected as SLIP RING or PART WINDING.
This is the time delay from the closure of Contactor A until the closure of
Contactor B.
Range: 1S-2S, 2S-1S
Appears only if STARTER TYPE is selected as AUTOTRANS OPN TRANS. The
1S-2S value means that the 1S contactor will close ahead of the 2S
contactor as per some manufacturer wiring practices. The 2S-1S value
means that the 2S contactor will close ahead of the 1S contactor, another
common wiring practice.
Range: 1 to 125 seconds; Step: 1 second
Appears only if STARTER TYPE is selected as AUTOTRANS OPN TRANS or
AUTOTRANS CLS TRANS. This is the time delay from the closure of
Contactor A until the opening of Contactor A.
Range: 1 to 40 starts/hour or OFF; Step: 1
Limits the number of starts per hour to prevent over heating of windings.
