GE MM3 Instruction Manual page 111

6 COMMUNICATIONS
Table 6–12: MODBUS MEMORY MAP (Sheet 6 of 19)
REGISTER
GROUP MODICON ADDRESS
DEC
STARTER 44120 4119
continued
44121 4120
44122 4121
44123 4122
44124 4123
44125 4124
↓ ↓
44128 4127
CT/VT 44129 4128
INPUTS
44130 4129
44131 4130
44132 4131
44133 4132
44134 4133
44135 4134
44136 4135
THERMISTOR 44137 4136
44138 4137
44139 4138
44140 4139
THERMISTOR 44141 4140
SIMULATION
44142 4141
44143 4142
44144 4143
FAULT MODE 44145 4144
44146 4145
44147 4146
44148 4147
44149 4148
↓ ↓
44152 4151
MOTOR 44153 4152
PROTECTION
44154 4153
THERMAL
44155 4154
44156 4155
44157 4156
44158 4157
44159 4158
44160 4159
Notes: * – Maximum setpoint value and 65535 represent OFF
** – 1/Phase Current Scale Factor x A
*** – 101 represents unlimited
† – Minimum setpoint value represents OFF
~* – 0.1 x A when Hi resolution mode is disabled; 0.01 x A when enabled
GE Power Management
DESCRIPTION
HEX
1017 Changeover Time
1018 Reserved
1019 Starts per Hour
101A High Speed Start Block
101B Contactor Sequence
101C ...Reserved...
↓ ↓
101F ...Reserved...
1020 Phase CT Primary
1021 High Speed Phase CT Primary
1022 Ground CT Primary
1023 Ground Fault CT
1024 VT Primary Voltage
1025 VT Connection Type
1026 VT Secondary Voltage
1027 Nominal Frequency
1028 Cold Resistance
1029 Hot Resistance
102A Thermistor Trip
102B Thermistor Alarm
102C ...Reserved...
102D Simulation
102E Thermistor Resistance
102F Thermistor Simulation Period
1030 Internal Fault Trip
1031 Serial Comms Failure Trip
1032 Serial Comms Failure Alarm
1033 Change command mode on Alarm
1034 ...Reserved...
↓ ↓
1037 ...Reserved...
1038 Full Load Current
1039 High Speed Full Load Current
103A Overload Curve Number
103B Hot / Cold Curve Ratio
103C Overload Pickup Level
103D ...Reserved...
103E ...Reserved...
103F ...Reserved...
MM3 Motor Manager 3
6.5 MEMORY MAP
REGISTER STEP UNITS FOR-
VALUE VALUE AND MAT
RANGE SCALE
1-125 1 s F1
1-41 1 s F1*
0-1 1 -- F14
0-1 1 -- F32
... ... ... ...
↓ ↓ ↓
... ... ... ...
0-1000 5 A F1
5-1000 5 A F1
5-1000 5 A F1
0-2 1 --- F13
110-691 1 --- F1*
0-1 1 --- F15
110-240 10 V F1
50-60 10 Hz F1
1-300 1 0.1 x kW F1
1-300 1 0.1 x kW F1
0-1 1 --- F14
0-1 1 --- F14
... ... ... ...
0-1 1 F20
0-30000 1 ohms F1
5-305 5 min. F1**
0-1 1 --- F14
5-30 5 --- F1*
5-30 5 --- F1*
0-1 1 --- F14
... ... ... ...
↓ ↓ ↓
... ... ... ...
0-1000 1 **
F1
5-1000 1 ** F1
1-12 1 --- F1
20-100 1 % F1
100-125 1 0.01 x FLC F1
... ... ... ...
... ... ... ...
... ... ... ...
FACTORY
DEFAULT
VALUE
(CONVERTED)
5
5
0 = DISABLE
0 = 1S-2S
...
↓ ↓
...
†
0 = OFF
100
100
0=50:0.025 CBCT
691 = OFF
0 = PHASE (A-N)
120
60
1 = 0.1 kW
50 = 5.0 kW
0 = DISABLE
0 = DISABLE
...
0=OFF
0 ohms
6
15 min.
1 = ENABLE
30 = OFF
30 = OFF
0 = DISABLE
...
↓ ↓
...
† 0 = OFF
100
4
75
100 = 1.00 x FLC
...
...
...
6-23
