4 SETPOINTS
ANALOG ALARM LOW
MESSAGE
DELAY: 5 s
ANALOG ALARM HIGH
MESSAGE
LEVEL: OFF
ANALOG ALARM HIGH
MESSAGE
DELAY: 5 s
ANALOG TRIP LOW
MESSAGE
LEVEL: OFF
ANALOG TRIP LOW
MESSAGE
OVERRIDE: 5 s
ANALOG TRIP LOW
MESSAGE
DELAY: 5 s
ANALOG TRIP HIGH
MESSAGE
LEVEL: OFF
ANALOG TRIP HIGH
MESSAGE
OVERRIDE: 5 s
ANALOG TRIP HIGH
MESSAGE
DELAY: 5 s
GE Power Management
Range: 1 to 600 seconds or OFF; Step: 1 second
The analog input scaled value must be below the ANALOG ALARM LOW
LEVEL for the time specified by this setpoint before an alarm will occur.
Range: 1 to 20000 or OFF; Step: 1
If the analog input scaled value exceeds the level set by this setpoint, an
Analog Input High Alarm will occur. Note that the alarm level must be a
value between the MINIMUM SCALE and MAXIMUM SCALE values.
Range: 1 to 600 seconds or OFF; Step: 1 second
The analog input scaled value must be above the ANALOG ALARM HIGH
LEVEL for the time specified by this setpoint before an alarm will occur.
Range: 1 to 20000 or OFF; Step: 1
If the analog input scaled value drops below the level set by this setpoint,
an Analog Input Low Trip will occur. Note that the trip level must be a
value between the MINIMUM SCALE and MAXIMUM SCALE values.
Range: 1 to 125 seconds or OFF; Step: 1
The analog level must reach a healthy state (greater than trip level) after
a start within the amount of time set by this setpoint. If the value is 0, the
analog level must be healthy when a start is initiated or an analog trip will
occur immediately. If set to OFF, the trip will occur if the analog level is
unhealthy, regardless if the motor is running or stopped.
Range: 1 to 600 seconds or OFF; Step: 1 second
The analog input scaled value must be below the ANALOG TRIP LOW LEVEL
for the time specified by this setpoint before a trip will occur.
Range: 1 to 20000 or OFF; Step: 1
If the analog input scaled value exceeds the level set by this setpoint, an
Analog Input High Trip will occur. Note that the trip level must be a value
between the MINIMUM SCALE and MAXIMUM SCALE values.
Range: 1 to 125 seconds or OFF; Step: 1
The analog level must reach a healthy state (less than trip level) after a
start within the amount of time set by this setpoint. If the value is 0, the
analog level must be healthy when a start is initiated or an analog trip will
occur immediately. If the value is set to OFF, the trip will occur if the
analog level is unhealthy, regardless if the motor is running or stopped.
Range: 1 to 600 seconds or OFF; Step: 1 second
The analog input scaled value must be above the ANALOG TRIP HIGH LEVEL
for the time specified by this setpoint before a trip will occur.
MM3 Motor Manager 3
4.4 S3 PROCESS
4
4-25
