4 SETPOINTS
PATH: SETPOINTS MMMMMMM S7 TESTING MMMMM ANALOG INPUT SIMULATION
SIMULATION:
OFF
MESSAGE
SIMULATION ENABLED
MESSAGE
FOR: 15 min
ANALOG INPUT
MESSAGE
OFF mA
GE Power Management
Range: ON, OFF
Enter ON to switch from an actual analog input to the programmed
simulated value. Set this setpoint OFF after simulation is complete.
Range: 5 to 300 min. or UNLIMITED; Step: 5 min.
Select the desired length of time that simulation will be enabled. When
the programmed time has elapsed, analog input simulation will turn off. If
unlimited is selected, the simulated analog input will be used until
simulation is turned off via the simulation on/off message or via the serial
port or until control power is removed.
Range: 4.0 to 20.0 mA or OFF; Step: 1 mA
Enter an analog input current in the range of 4 to 20 mA to be simulated.
