4.8 MM3 STANDARD OVERLOAD CURVES
100000
10000
4
1000
100
10
1
Figure 4–2: GE POWER MANAGEMENT TIME/OVERCURRENT CURVES
K+E 11" x 17" format of time/overcurrent curves are available from factory upon request.
4-36
MM2/MM3 STANDARD TIME/CURRENT
GE POWER MANAGEMENT
MULTIPLE OF PICKUP CURRENT (PER UNIT)
MM3 Motor Manager 3
OVERLOAD CURVES
CURVE # CURVE #
8
7
6
5
4
3
2
1
4 SETPOINTS
807638D4.CDR
