APPENDIX A
Table A–1: MM3 COMMISSIONING (Sheet 5 of 8)
DESCRIPTION
IL7 Switch Type
Interlock Input 8
Startup Override Delay 8
Running Override Delay 8
Operation 8
Instantaneous Alarm 8
IL8 Switch Type
Interlock Input 9
Startup Override Delay 9
Running Override Delay 9
Operation 9
Instantaneous Alarm 9
IL9 Switch Type
Interlock Input 10
Startup Override Delay 10
Running Override Delay 10
Operation 10
Instantaneous Alarm 10
IL10 Switch Type
Local Isolator
Auto Permissive Indication
Auto Mode
Serial Permissive
Start Block Alarm
Disable Command Mode Change
INTERLOCK NAMES
Process Interlock A Name
Process Interlock B Name
Process Interlock C Name
Process Interlock D Name
Process Interlock E Name
Process Interlock F Name
Process Interlock G Name
Process Interlock H Name
Process Interlock I Name
GE Power Management
DEFAULT
USER VALUE
N.O.
Not Used
0 sec.
0 sec.
Stop
Disable
N.O.
Not Used
0 sec.
0 sec.
Stop
Disable
N.O.
Not Used
0 sec.
0 sec.
Stop
Disable
N.O.
Disable
Manual
Serial
Disable
Disable
Disable
Interlock A
Interlock B
Interlock C
Interlock D
Interlock E
Interlock F
Interlock G
Interlock H
Interlock I
MM3 Motor Manager 3
A.1 COMMISIONING SUMMARY
Table A–1: MM3 COMMISSIONING (Sheet 6 of 8)
DESCRIPTION
Process Interlock J Name
Intlk Counter Name
Intlk Counter Units
STOP CONFIGURATION
Field Stop
Faceplate Stop
Process Stop
ANALOG INPUT
Analog Input Name
Analog Input Units
Minimum Scale: 4 mA
Maximum Scale: 20 mA
Analog Alarm Low Level
Analog Alarm Low Delay
Analog Alarm High Level
Analog Alarm HIgh Delay
Analog Trip Low Level
Analog Trip Low Override
Analog Trip Low Delay
Analog Trip High Level
Analog Trip High Override
Analog Trip High Delay
S4: CONTROL
UNDERVOLTAGE AUTO RESTART
Undervoltage Restart
Immed. Restart Power Loss Time
Delay Restart Power Loss Time
Restart Time Delay
AUX 1 RELAY CONFIG
Aux. Relay 1 Function
Aux. Relay 1 Delay
Aux. Relay 1 Pre Start Delay
Aux. Relay 1 Post Start Delay
Energize On Motor Start Delay
De-energize on Motor Stop Delay
DEFAULT
USER VALUE
Interlock J
Intlk Counter
Units
Unlatched
Unlatched
Unlatched
Analog Input
Units
0
1000
Off
5 sec.
Off
5 sec.
Off
5 sec.
5 sec.
Off
5 sec.
5 sec.
Enable
200 ms
2.0 sec.
2.0 sec.
Serial Control
5 sec.
5 sec.
Off
5 sec.
5 sec.
A-3
A
