3.1 USER INTERFACE
• RUNNING: Whenever contactor A and/or B relays are closed and the contactor status inputs acknowledge
the correct state, the RUNNING indicator will be on. Current flow does not affect the indicator, only contac-
tor status.
• STOPPED: If both contactors A and B are in the OFF state, the STOPPED indicator will be on.
• TRIPPED: If a trip condition causes the A or B contactor relays to de-energize, this indicator will be on. As
long as this indicator is on, the motor cannot be started. It is cleared using the reset key, lockout reset facil-
ity or serial port reset, dependent on the type of trip.
• ALARM: If an alarm condition is present this indicator will be on. Use A2: STATUS \ ALARM DATA to view cur-
rent alarm status.
3
• FAULT: If an internal fault within the MM3 is detected by self-checking, this indicator will be on. The MM3
must be replaced or repaired.
• CONTACTOR A: If the Contactor A Relay is energized, this indicator will be on.
• CONTACTOR B: If the Contactor B Relay is energized, this indicator will be on.
• AUX 1: If Auxiliary Relay # 1 is on, this indicator will be on.
• AUX 2: If Auxiliary Relay # 2 is on, this indicator will be on.
• AUTO: If the MM3 is in Auto control mode or the Hard-Wired Auto mode, this indicator will be on. In Auto
mode the Start A / Start B switch inputs and
commands are operational. In the Hardwired Auto Mode, the Auto Start A and Auto Start B switch inputs
are functional in conjunction with the Auto Permissive switch input. Serial, faceplate and remote starts are
disabled. STOP commands from any location are always operational.
• MANUAL: If the MM3 is in Manual control mode, this indicator will be on. In Manual mode the Start A /
Start B switch inputs, AUTO START A / AUTO START B switch inputs and
tional but serial port start commands are ignored. All stop commands are operational.
