Publication No. 981090
September 1995
Supersedes
October 1994
SERVICE MANUAL for the
Kodak X-Omat M43 and M43A PROCESSORS
and the Kodak X-Omat Clinic 1 PROCESSOR
H130_0009DA
HEALTH SCIENCES DIVISION
© Eastman Kodak Company
