Uponor Smatrix Move PRO Installation And Operation Manual page 90

EN
Enter Melting State Conditions
This menu enables access to parameters used when
CZ
to switch the meltaway state in the zone to and from
MELTING. When entering MELTING state the zone stays
in that condition until the min limit set in Min. Time in
DE
Melting is met.
The zone switches from IDLE to MELTING state when
DK
one of the following scenarios are met:
1. No ground moisture is detected and the measured
ground temperature is lower than than the set limit
EE
in Ground Temperature Limit.
2. No ground moisture is detected and the measured
ES
outdoor temperature is lower than than the set limit
in Outdoor Temperature Low Limit.
The zone switches from PROTECTION to MELTING
FI
when the primary return sensor measures a supply
temperature that is higher than PRIMARY RETURN
TEMP. HIGH, set in Automatic Freeze Protection .
FR
MENU TREE
HR
Enter Melting State
Conditions
HU
IT
LT
LV
NL
NO
PL
PT
RO
RU
SE
SK
9 0
Ground Temperature Limit
Outdoor Temp. Offset
Outdoor Temperature Low
Limit
Min. Time in Melting
GROUND TEMPERATURE LIMIT
In this menu the ground temperature limit, used to
switch meltaway state between IDLE to MELTING , is
set.
To set the ground temperature limit:
1. Select Ground Temperature Limit.
2. Press the navigation wheel to confirm selection.
3. Select Low Limit.
4. Press the navigation wheel to confirm selection.
5. Set the value.
Default: 2 ˚C
Setting range: 0 – 10 ˚C, 1 ˚C increments
6. Confirm the new setting by pressing the navigation
wheel again.
OUTDOOR TEMP. OFFSET
In this menu the outdoor temperature offset, used to
switch meltaway state from IDLE to MELTING, is set.
To set the outdoor temperature offset:
1. Select Outdoor Temp. Offset.
2. Press the navigation wheel to confirm selection.
3. Set the value.
Default: 1 ˚C
Setting range: -5 – 5 ˚C, 1 ˚C increments
4. Confirm the new setting by pressing the navigation
wheel again.
