Manual Operation
This menu enables access to manual operation mode in
the zone.
When manual operation mode is activated, access to
manual control (override) of the circulation pump and
mixing valve is enabled.
MENU TREE*
Manual Operation
Manual Mode
Pump
Mixing valve
* Parts of the menu tree may only be visible in the Move PRO
controller depending on its current configuration.
To activate manual operation mode:
1. Select Manual Mode.
2. Press the navigation wheel to confirm selection.
3. Select On.
4. Confirm the new setting by pressing the navigation
wheel again.
PUMP
In this menu the pump can be overidden and turned on
or off manually.
To override the circulation pump operation:
1. Select Pump.
2. Press the navigation wheel to confirm selection.
3. Select Manual.
4. Select On.
Default: Off
Setting range: Off/On
5. Confirm the new setting by pressing the navigation
wheel again.
U P O N O R S M AT R I X M O V E P R O · I N S TA L L AT I O N A N D O P E R AT I O N M A N U A L
MIXING VALVE
In this menu the mixing valve can be overriden opened
or closed manually.
To override the mixing valve setting:
1. Select Mixing valve.
2. Press the navigation wheel to confirm selection.
3. Select Manual.
4. Set the override value.
Default: 0 %
Setting range: 0 – 100 %, 1 % increments.
5. Confirm the new setting by pressing the navigation
wheel again.
