Supply temperature
The current supply temperature is shown. The
temperature is measured by the supply temperature
sensor wired to the controller.
Calculated Supply Setpoint
The calculated supply temperature is shown. The
setpoint is calculated using the sensor setup selected in
Heating Mode.
DHW Circ. Return Temp
The current return temperature is shown.
This information is only shown if Zone Setup is set to
Domestic Hot Water.
Indoor temperature
The current indoor temperature for the zone is shown.
If the zone is setup as Stand Alone Control the
temperature is measured by a room temperature sensor
wired to the Move PRO controller.
If the zone is setup as Smatrix Base PRO the Base
PRO controller sends either Average or Worst Case
(setup in the startup wizard) temperatures from the
Base PRO system.
This information is only shown if Heating Mode is set
to Outdoor + Indoor comp..
ECO-Comf Status
The current ECO/Comfort for the zone status is shown.
This information is only shown if Zone Setup is set to
Stand Alone Control and Heating Mode is set to
Outdoor + Indoor comp..
Mixing Valve
The status of the mixing valve is shown. 0 % (supply
from heat source closed) – 100 % (supply from heat
source fully opened).
Pump
The status of the circulation pump is shown (on/off).
This information is only shown if Zone Setup is set to
Stand Alone Control or Domestic Hot Water.
U P O N O R S M AT R I X M O V E P R O · I N S TA L L AT I O N A N D O P E R AT I O N M A N U A L
z 3 i
one nformation
This menu shows information about zone 3.
Menu tree*
Zone 3 Information
Zone Setup
Heating Mode
Heating Curve
Supply temperature
Calculated Supply Setpoint
Indoor temperature
ECO-Comf Status
Meltaway Curve
Return temperature
Ground Temperature
Ground Moisture
Primary Return Temperature
Status
Mixing Valve
Pump
* Parts of the menu tree may only be visible in the Move PRO
controller depending on its current configuration.
Zone Setup
The selected zone setup is shown:
• Stand Alone Control
• Smatrix Base PRO (integrated with a Smatrix Base
PRO system)
• Meltaway
Heating Mode
The selected heating mode for the zone is shown:
• Outdoor (only the outdoor temperature sensor is
used)
• Outdoor + Indoor comp. (the outdoor temperature
sensor is used together with room temperature
data)
This information is only shown if Zone Setup is set to
Stand Alone Control or Smatrix Base PRO.
