3 Uponor Smatrix Move PRO
Uponor Smatrix Move PRO is a supply temperature
control system for use in different zones. The number of
zones and setup vary depending on which application
package (supplied with the controller) has been
installed (inserting the microSD card into the controller).
This manual only reflects the installation of the
controller together with the heating application
package.
Heating application
Using the heating application, enables up to four zones
to be setup for heating with different radiant systems
(such as underfloor loops, radiators etc.), domestic hot
water, or snow melting (keeping large areas clear of
snow).
Heating/cooling application
Using the heating/cooling application enables up to
three zones to be setup for heating and/or cooling with
different radiant systems (such as underfloor loops,
ceiling panels etc.), domestic hot water, or snow melting
(keeping large areas clear of snow)
U P O N O R S M AT R I X M O V E P R O · I N S TA L L AT I O N A N D O P E R AT I O N M A N U A L
3.1

System overview

Uponor Smatrix Move PRO consists of a controller and a
wide array of sensors. Together they control the supply
temperature in each zone by managing the connected
valve actuators and circulation pumps. The zones can be
setup as follows.
Zone Setup alternatives
1 Stand Alone Control
Smatrix Base PRO
2 Stand Alone Control
Smatrix Base PRO
Domestic Hot Water
3
Stand Alone Control
Smatrix Base PRO
Meltaway
4
Stand Alone Control
Smatrix Base PRO
Meltaway
Stand Alone Control
If the zone is setup as Stand Alone Control, the
controller operates without individual room control.
The supply temperature setpoint is calculated using
an outdoor sensor and an optional room temperature
sensor.
The optional room temperature sensor is placed in
a reference area and enables an indoor temperature
setpoint parameter. It is used to keep the indoor
temperature as close as possible to the indoor
temperature setpoint.
