Heating Curve
This menu shows the heating curve, and max/min
CZ
supply temperature limits, for the zone.
This information is only shown if Zone Setup is set to
DE
Stand Alone Control or Smatrix Base PRO.
Supply temperature
DK
The current supply temperature is shown. The
temperature is measured by the supply temperature
sensor wired to the controller.
EE
Calculated Supply Setpoint
ES
The calculated supply temperature is shown. The
setpoint is calculated using the sensor setup selected in
Heating Mode.
FI
Indoor temperature
The current indoor temperature for the zone is shown.
FR
If the zone is setup as Stand Alone Control the
temperature is measured by a room temperature sensor
wired to the Move PRO controller.
HR
If the zone is setup as Smatrix Base PRO the Base
PRO controller sends either Average or Worst Case
HU
(setup in the startup wizard) temperatures from the
Base PRO system.
This information is only shown if Heating Mode is set
IT
to Outdoor + Indoor comp..
ECO-Comf Status
LT
The current ECO/Comfort for the zone status is shown.
This information is only shown if Zone Setup is set to
LV
Stand Alone Control and Heating Mode is set to
Outdoor + Indoor comp..
NL
Meltaway Curve
This menu shows the meltaway curve, and max/min
NO
supply temperature limits, for the zone.
This information is only shown if Zone Setup is set to
Meltaway.
PL
Return temperature
PT The current return temperature is shown.
This information is only shown if Zone Setup is set to
Meltaway.
RO
RU
SE
SK
4 2
Ground Temperature
The current temperature in the ground around the snow
sensor is shown.
This information is only shown if Zone Setup is set to
Meltaway.
Ground Moisture
This parameter shows if there is moisture around the
snow sensor.
Primary Return temperature
The current primary return temperature is shown.
This information is only shown if Zone Setup is set to
Meltaway.
Status
This parameter shows the current meltaway status.
Stop: Meltaway is inactive.
Idle: Meltaway is idle and the supply temperature is
kept low to keep the zone from getting too cold.
Melting: Meltaway is active.
Protection: Protecting the heat source from low return
temperatures.
The status may change, in case of sensor fault. An alarm
will also be shown in the display if that is the case.
This information is only shown if Zone Setup is set to
Meltaway.
Mixing Valve
The status of the mixing valve is shown. 0 % (supply
from heat source closed) – 100 % (supply from heat
source fully opened).
Pump
The status of the circulation pump is shown (on/off).
This information is only shown if Zone Setup is set to
Stand Alone Control or Meltaway.
