MIXING VALVE
In this menu the mixing valve can be overriden opened
or closed manually.
To override the mixing valve setting:
1. Select Mixing valve.
2. Press the navigation wheel to confirm selection.
3. Select Manual.
4. Set the override value.
Default: 0 %
Setting range: 0 – 100 %, 1 % increments.
5. Confirm the new setting by pressing the navigation
wheel again.
Pump
This menu enables access to pump settings in the zone.
This menu is only shown if Zone Setup is set to Stand
Alone Control for the zone.
MENU TREE*
Pump
Pump Exercise
Exercise Day of the Week
Exercise Hour
Exercise Min
* Parts of the menu tree may only be visible in the Move PRO
controller depending on its current configuration.
PUMP EXERCISE
In this menu pump exercise can be activated.
To activate pump exercise:
1. Select Pump Exercise.
2. Press the navigation wheel to confirm selection.
3. Select Pump Exercise.
Default: No Exercise
Setting range: No Exercise/Pump Exercise
4. Confirm the new setting by pressing the navigation
wheel again.
U P O N O R S M AT R I X M O V E P R O · I N S TA L L AT I O N A N D O P E R AT I O N M A N U A L
EXERCISE DAY OF THE WEEK
In this menu the day of the week for pump exercise is
set.
This menu is only shown if Pump Exercise is set to
Pump Exercise.
To select a day of the week for pump exercise:
1. Select Exercise Day of the Week.
2. Press the navigation wheel to confirm selection.
3. Select a day.
Setting range: Monday – Sunday
4. Confirm the setting by pressing the navigation
wheel again.
EXERCISE HOUR
In this menu the hour of the day for pump exercise is
set.
This menu is only shown if Pump Exercise is set to
Pump Exercise.
To select an hour of the day for pump exercise:
1. Select Exercise Hour.
2. Press the navigation wheel to confirm selection.
3. Set the value.
Default: 8 h
Setting range: 0 – 23 h, 1 h increments
4. Confirm the setting by pressing the navigation
wheel again.
EXERCISE MIN
In this menu the minute of the hour for pump exercise
is set.
This menu is only shown if Pump Exercise is set to
Pump Exercise.
To select a minute of the hour for pump exercise:
1. Select Exercise Min.
2. Press the navigation wheel to confirm selection.
3. Set the value.
Default: 0 min
Setting range: 0 – 59 min, 1 min increments
4. Confirm the setting by pressing the navigation
wheel again.
