Uponor Smatrix Move PRO Installation And Operation Manual page 72

EN
Comf. - ECO
This menu enables access to settings related to the
CZ
controller Comfort/ECO modes.
This menu and its submenus are only shown if Zone
DE
Setup is set to Stand Alone Control and if Heating
Mode is set to Outdoor + Indoor comp. for the zone.
DK
MENU TREE
Comf. - ECO
EE
ES
ECO SETBACK
In this menu the ECO setback temperature is set. The
FI
parameter reduces the current setpoint with the set
value.
FR
If the setback is set to 0 the zone will resume its normal
operation, even if it is set in ECO mode.
To set the ECO setback value:
HR
1. Select ECO Setback.
2. Press the navigation wheel to confirm selection.
HU
3. Set the value.
Default: 4.0 ˚C
IT
Setting range: 0.0 – 10.0 ˚C, 0.1 ˚C increments
4. Confirm the new setting by pressing the navigation
LT
wheel again.
ECO-COMF STATUS
LV
This menu shows if the zone is set in ECO or Comf
(comfort) mode.
ECO-COMF SCHEDULE
NL
In this menu a schedule for switching between Comfort
and ECO mode can be created.
NO
The default schedule is set to Comfort mode 24h a day,
7 days a week.
PL
W !
arning
Ensure that different schedules cannot enable
ECO and Comf and the same time. This may
PT
cause an error where the controller must be
reset to factory default values.
RO
RU
SE
SK
7 2
ECO Setback
ECO-Comf Status
ECO-Comf Schedule
To edit/create the ECO-Comf Schedule:
1. Select ECO-Comf Schedule.
2. Press the navigation wheel to confirm selection.
The current schedule is showing.
3. Select a day.
4. Press the navigation wheel to confirm selection.
All current schedule settings are shown, each line
representing a switch between Comfort and ECO
mode. If entering the menu for the first time only
one line is present, showing Comf starting at 00:00
every day of the week.
5. Select an existing line to edit or 00:00 Add new to
add a new setting.
6. Select wether to edit the hours, minutes, mode or
day of the week.
HOURS:
Set at which hour the mode will start and press the
navigation wheel to confirm selection.
MINUTES:
Set at which minte of the hour the mode will start
and press the navigation wheel to confirm selection.
MODE:
Select a mode which should start at the set time
and press the navigation wheel to confirm selection.
Select between Comf, ECO and Delete switch
time. Delete switch time erases the current line
when selecting OK and pressing the navigation
wheel.
DAY OF THE WEEK:
Select which days of the week, at the set time the
selected mode should start.
7. Select OK at the end of the line, when done, and
press the navigation wheel to confirm selection.
A new line has been added to the schedule.
8. Redo steps 5 and 6 until the schedule is complete.
9. Press the back button on the controller to exit the
schedule setup.
