Uponor Smatrix Move PRO Installation And Operation Manual page 52

EN
Heating Curve
This menu enables access to heating curve settings for
CZ
the zone. Settings such as the slope (Setting) and offset
of the heating curve.
DE
This menu is only shown if Zone Setup is set to Stand
Alone Control for the zone
DK
MENU TREE
Heating Curve
EE
ES
SETTING
In this menu the slope of the heating curve is selected.
FI
To select a heating curve:
1. Select Setting.
FR
2. Press the navigation wheel to confirm selection.
3. Set the value.
HR
Default: 0.9
Setting range: 0.1 – 1.6, 0.1 increments
HU
4. Confirm the new setting by pressing the navigation
wheel again.
IT
OFFSET
In this menu the the heating curve can be offset. The
offset can be used for temporary changes to the heating
LT
curve.
To offset the heating curve:
LV
1. Select Offset.
2. Press the navigation wheel to confirm selection.
NL
3. Set the value.
Default: 0
NO
Setting range: -8 – 8, 1 increments
4. Confirm the new setting by pressing the navigation
wheel again.
PL
HEATING CURVE
This menu shows the heating curve, and max/min
PT
supply temperature limits, for the zone.
RO
RU
SE
SK
5 2
Setting
Offset
Heating Curve
Manual Operation
This menu enables access to manual operation mode in
the zone.
When manual operation mode is activated, access to
manual control (override) of the circulation pump and
mixing valve is enabled.
MENU TREE*
Manual Operation
* Parts of the menu tree may only be visible in the Move PRO
controller depending on its current configuration.
To activate manual operation mode:
1. Select Manual Mode.
2. Press the navigation wheel to confirm selection.
3. Select On.
4. Confirm the new setting by pressing the navigation
wheel again.
PUMP
In this menu the pump can be overidden and turned on
or off manually.
To override the circulation pump operation:
1. Select Pump.
2. Press the navigation wheel to confirm selection.
3. Select Manual.
4. Select On.
Default: Off
Setting range: Off/On
5. Confirm the new setting by pressing the navigation
wheel again.
U P O N O R S M AT R I X M O V E P R O · I N S TA L L AT I O N A N D O P E R AT I O N M A N U A L
Manual Mode
Pump
Mixing valve
