4.3

Installation example

CZ
u s
Ponor matrix
4
A
DE
DK
3
A
EE
2
A
ES
FI
1
A
FR
HR
HU
A connection example of Uponor Smatrix Move PRO
IT
Controller (with the heating application installed)
regulating four different zones (setup as underfloor
heating with a Stand Alone Control, underfloor
LT
heating with a Smatrix Base PRO system, Domestic
Hot Water production, or melting snow with
Meltaway).
LV
The installation will work in a standard way with a wide
range of sensors regulating each zone according to set
NL
temperatures (setpoints).
The supply is routed to the zones using either a three-
way mixing valve (B), or using a two-way valve together
NO
with a heat exchanger (A).
N O T E !
PL
When using a 3-way mixing valve (option B)
in a meltaway zone, a heat exchanger may
be needed. This creates a secondary loop
PT
where water mixed with antifreeze additives
circulate.
See also the wiring diagram in the end of the manual.
RO
RU
SE
SK
1 2
m Pro
ove system
B
Base
PRO
B
Base
PRO
B
A/B A/B
Base
PRO
B
Base
PRO
Stand Alone Control
B
The following components are required for heating
operation in the zone (regulate the zone temperature
using a mixing valve).
• Supply sensor S-152
Optional:
• Room sensor S-155
The outdoor temperature sensor is not needed if the
Move PRO controller is integrated with an Uponor
Smatrix Base PRO system (with outdoor temperature
sensor).
See section 5 Install Uponor Smatrix Move PRO
controller for more information.
SYSTEM SETTINGS IN STARTUP WIZARD
Enable Zone # (# = 1, 2, 3, or 4): Yes
Zone setup: Stand Alone Control
Heating Mode: Outdoor (outdoor temperature sensor
Other zone settings can be found in the menu system
Settings > Zone # Setting (where # is the zone where
Stand Alone Control is activated).
See section 5.13 Startup wizard for more information.
See section 7.10 Settings for more information.
U P O N O R S M AT R I X M O V E P R O · I N S TA L L AT I O N A N D O P E R AT I O N M A N U A L
A B
If the zone (1 through 4) is setup as Stand Alone
Control, basic control of the system is enabled.
only)
Outdoor + Indoor comp. (outdoor
temperature sensor with optional room
temperature sensor)
