Heating Curve
This menu enables access to heating curve settings for
the zone. Settings such as the slope (Setting) and offset
of the heating curve.
This menu is only shown if Zone Setup is set to Stand
Alone Control for the zone
MENU TREE
Heating Curve
Setting
Offset
Heating Curve
SETTING
In this menu the slope of the heating curve is selected.
To select a heating curve:
1. Select Setting.
2. Press the navigation wheel to confirm selection.
3. Set the value.
Default: 0.9
Setting range: 0.1 – 1.6, 0.1 increments
4. Confirm the new setting by pressing the navigation
wheel again.
OFFSET
In this menu the the heating curve can be offset. The
offset can be used for temporary changes to the heating
curve.
To offset the heating curve:
1. Select Offset.
2. Press the navigation wheel to confirm selection.
3. Set the value.
Default: 0
Setting range: -8 – 8, 1 increments
4. Confirm the new setting by pressing the navigation
wheel again.
HEATING CURVE
This menu shows the heating curve, and max/min
supply temperature limits, for the zone.
U P O N O R S M AT R I X M O V E P R O · I N S TA L L AT I O N A N D O P E R AT I O N M A N U A L
Meltaway Curve (IDLE Status)
This menu enables access to meltaway heating curve
settings for the zone while in IDLE status. Settings
such as the slope (Setting) and offset of the meltaway
heating curve.
This menu is only shown if Zone Setup is set to
Meltaway and if Heating Curve Meltaway is enabled
for the zone.
MENU TREE
Meltaway Curve (IDLE
Status)
Setting
Offset
Heating Curve
SETTING
In this menu the slope of the meltaway heating curve is
selected.
To select a meltaway heating curve:
1. Select Setting.
2. Press the navigation wheel to confirm selection.
3. Set the value.
Default: 0.9
Setting range: 0.1 – 1.6, 0.1 increments
4. Confirm the new setting by pressing the navigation
wheel again.
OFFSET
In this menu the the meltaway heating curve can be
offset. The offset can be used for temporary changes to
the heating curve.
To offset the meltaway heating curve:
1. Select Offset.
2. Press the navigation wheel to confirm selection.
3. Set the value.
Default: 0
Setting range: -8 – 8, 1 increments
4. Confirm the new setting by pressing the navigation
wheel again.
HEATING CURVE
This menu shows the meltaway heating curve, and max/
min supply temperature limits, for the zone.
