PIPER COMANCHE SERVICE MANUAL
TABLE V·U. TROUBLESHOOTING OIART (St1R.FACE CONTR.OLS)
(COIle.)
Trouble
CauIC
Remedy
STAIULATOR CONTROL SYSTEM
LOSt motion between Cable eension too low. Adjust cable tmsion per
conrrol wheel
Table V-I.
and stabilator.
Broken pulley. Replace pulley.
Cables not
in
place on Install cables correctly.
pulleys.
Resistance to subilator System not lubricated Lubricate system. <Refer
conrrol movement. properly.
to Lubrication
Chart. Section II.)
Cable tension tOO hich. Adjust cable tension per
Table
V-\.
PuUeys bindint or nab- Replace bindint pullcys
bins· and/or provide
cle:annce between
pulleys and brackca.
Cables not in place on
Install cables correctly.
pulleys.
Cables croued or Check rourin, of control
routed ineerreetlv. cables.
Incorrect subilator Scabilator seop bolts Adjust stop screws
j)eT
cravel. incorrectly adjusted.
Parqral'h 5·35.
Correct subilator Scabilator cables incor-
Ril cables in aceor-
mvel cannot rectly riged. dance with Para-
be obwned by graph 5-35.
adjusting stop
bolts.
SURFACE CONTROLS
