PIPER COMANCHE SERVICE MANUAL
3. Connect the external battery to thc cxtcm&l power reccptaclc; tum muter switch ON and
Start engine using normal
starting
procedure.
4-.
Tum MUtCr switch
OFF;
remove cxtemal banery. and then reconnect the banery at the
negative tenninal.
S. Tum
mum
switch ON.
When stattirll with a power
cart
and the airplafte's
bantry is
narty depicted. the procedure in Step a
need not be followed. Thc capacity of a power
Caft
is
suffiC:icnt to ltan an
aircraft
with a low battery.
9-97. Removal And Innalladon Ofllantry. (JlA·2.... 180. Serial Nos. 24-1 to :!4-102 iacl.) The battery is
located in the engine companment at the upper left side of the firewall. The battery may be removed by
the followin, procedure:
a. Remove the left side and top cowl.
b. Remove the cover of the box by removiftl the win, nuts
at
the fore and aft sides of the cover.
c. Disconnect the banery cables.
NOTE
Always remove the Jround cable
flnt -and insuIl
last to prevent
accidental shorr circuirin, or arcing.
d. Lift the battery from the box.
e. The battery may be installed in reverse order of removal.
9-98. Removal And InRl1Jation Of Battery. (PA-2~180
and
PA·2~2S0.
Serial SOS. 24-103 and u!':
PA-24-260. Serial Sos. 2+-4-000 to 2442%. 24-4-248 to 24-4299 incl. and
2~783.
240-8403 Ind up; and
PA·24-400. Serial Sos. 26-1 Ind ue.) The battery is located in the lower aft section of the fusclage directly
aft of the bI.!Jp¥e compartment. The battery
ma~'
be removed bv the follow"" procedure:
a. Remove the access panel to the aft section of the
fusela~
located
I t
the aft of the balfage
compartment.
b. Remove the cover of the box by removin, wing nuts at the fore and aft sides of the cover.
C.
Disconnect the battery cables.
NOTE
Alwavs remove the around cable fint and instaU last to prevent
aCCidental shon circuinn.. or arcin...
d.
Lift the battery from the box.
e. The battery may be inn.alled in reverse order of removal.
ELECTRICAL SYSTEM
ISSUED: 8/18/12
3
C22
•
•
•
