System Start-Up

Switching on the System

The VisionMaster workstation is designed such that one switch at the
workstation typically applies power to that workstation's computer and
monitor.
In a multi-node system, as the system is started, the software automatically
establishes communication with other workstations that may already be
running.
To start up the system press the On/Off rocker switch, located on the
underside of the control panel. When this switch is turned On the system
powers up.
The On/Off switch is the only system control accessible to the
operator. Do NOT remove the front panel.
When starting up the system always leave at least one minute
after the system has powered down before switching the On/Off
switch to On.
2-5
CAUTION:
Basic Operation of ECDIS
65900012
