ECDIS User Guide
2. To centre the display on the selected LAT/LON location click the
Goto button.
When a location has been entered the system draws an orange
diamond symbol with a short line below the symbol and a dot at
the end of the line.
3. To enter a bearing for the tide/sea current, click in the BRG field and
move the trackball to the right until the required value is displayed.
Left click to enter the bearing value.
4. To enter a speed for the tide/sea current, click in the Speed field and
move the trackball to the right until the required value is displayed.
Left click to enter the speed value.
5. The entry time defaults to the current data and time. To enter a
different time click in the field, the data changes to green and an
editing window appears directly below the time field. Enter a value
using the editing arrows; click the OK button when the required time
value is displayed.
6. With the required values entered in the New Current Entry area click
the Add Entry button. The time, bearing and speed values for the
tide/sea current are listed in the station's table.
7. Repeat the process to enter more
tide/sea current values. Each entry is
listed in the table.
8. To remove an entry, select from the list
and click the Remove Row button, the entry is removed from the list.
9. To save the station data click the Save button. A `Save Station'
popup window appears prompting to name the station.
10. Enter a suitable name and click the OK
button. The popup window is removed
and the name appears in the Station
Name field.
11. To remove a station from the chart click
the Clear/New button.
65900012
Charts
4-87
