Sperry Marine Visionmaster FT ECDIS User Manual page 35

ECDIS User Guide
Ship's heading and
speed display
Selection of Sensor
Source
Selection of
presentation mode
Motion Mode
Selection of vector
mode
Chart Facilities
Chart Symbols Colour
Diagram
Defining and displaying
EBLs, VRMS & ERBLs
Extensive alert
indications
(Alarms, Warnings and
Cautions)
Temporary and
Permanent prompts
65900012
Compass alignment.
Selection of speed mode (through water or over
ground).
Selection of water or ground stabilisation
Selection of sensor source for data type
(heading, STW , position etc.)
North-up or Course-up
True Motion (TM) only
Selection of true ( T ) or relative ( R ) vectors.
Selection of vector time.
Enables vector and raster charts installed from
an installer facility to be displayed.
Chart feature sets can be customised and
manually updated by the operator.
Ensures any adjustments made to brightness
and contrast settings will enable chart symbol
SENC data, such as coastlines, safety contour
and other objects to be adequately displayed.
Two electronic bearing lines – EBL 1 & EBL 2.
Two variable range markers – VRM 1 & VRM 2.
Each EBL/VRM pair can be displayed as a
combined ERBL – ERBL 1 and/or ERBL 2.
Displaying the current unacknowledged alert
with highest priority in the alert status indicator.
Facility for acknowledging alerts in a status
indicator.
Display all alerts, listed in groups of alarms,
warnings and cautions, or sorted by group.
Alert buzzer facility.
Watch alarm facility.
Both Temporary and Permanent prompts are
displayed below alerts.
Overview
1-13
