Scanner Assembly
optional Performance Monitor. If the system includes an integral
transceiver then this also forms part of the Scanner Assembly. If the
system uses a bulkhead transceiver then the transceiver unit is not
included in the Scanner assembly.
Antenna Unit. 10cm S-band (9 or 12ft aperture) or 3cm X-band (4,
6 or 8 ft aperture).
Performance Monitor. If fitted, the performance Monitor Antenna
is mounted on the Turning Unit.
Transceiver. Masthead (mounted as an integral part of the
Scanner assembly) or Bulkhead (mounted as a separate unit below
decks).
Scanner Control Unit – for switching the scanner on and off – are
supplied for S-band radars only.
Console Assembly - supplied as a standalone 250 tabletop and 340
tabletop/deck mounted console (including pedestal); or a kit version for
installation into an existing console suite. The 250/340 console assembly
includes the following modules:
Input/Output (PCIO) Unit - receives data inputs from the
transceiver and external sensors; outputs data to the processor
unit.
Processor Unit - a single PC running Windows XP operating
system.
Display Unit - includes a flat panel monitor
Control Panel - There are two types of control panel: Basic and
Enhanced. The basic control panel only includes a trackball with
left and right keys. The enhanced control panel includes the
following additional group of controls: Rotary controls and
Adjustment & Acknowledgement buttons.
The console assembly may also be supplied as a 19" Integrated Tabletop,
where the Monitor, PCIO, Processor and control panel are all contained in
a single mechanical housing.
2
A Scanner assembly may also be referred to as a `Top Unit'.
65900012
2
. Comprises an Antenna unit, a Turning unit and an
