Routes

Route Status

A summary of the active leg of a monitored route is shown in the Route
Status window. The information in this window is also shown in the Route
tab folder of the Monitor Route sub menu.
The information in the Route Status window includes the following:
Name
Route
Progress
XTD
DWOL
TWOL
ETA
8-48
The name of the route currently monitored.
The state of ship on route e.g. 'Sailing To WPT6 (6/7)'
denotes next waypoint on route and total number of
waypoints.
XTD (Cross Track Distance) is the off track distance on
either the Port side (PORT) or Starboard side (STBD) from
the monitored route.
Distance to go to the next wheelover leg.
Time to go along the leg to next wheelover based on
present ship speed.
Estimated Time of Arrival at the end of the route using own
ship SOG for this leg and planned speeds for future legs
(UTC or Local time).
