Charts
Highlighting and Viewing Date Dependent Objects
A chart object or radar mapping object may have a
specific date, or a specific date range assigned for
the display of the object. If the date dependency is
set for a future time period the object will not be
displayed on the screen until the particular day or
date has been reached.
Date dependent objects may be viewed by ticking the Highlight Objects
check box and selecting a particular date or date range by ticking the
Display Date or Date Range radio buttons clicking in the data
field and using the Forward and Back arrows on the subsequent
drop down keypad.
When Highlight Objects is enabled and the day or date range
dependency selected the object is shown on the display with an
orange diagonal line with a d in a small box at the end of the line.
All date dependent objects for a particular defined day or date range will be
shown on the screen.
ENC Text
The chart display settings listed below are available for ENC text symbols.
Feature
Important
Displays text important for navigation.
Text
Displays other text information, including Names,
Other Text
Lights description and All Other settings information
Other Text
Displays name text information
- Names
Other Text
- Light Displays light description information
Description
Displays other text information (this is all other
Other Text
information that does not include names or light
- All Other
descriptions)
4-40
Description
ECDIS User Guide
Default
Value
On
Off
Off
Off
Off
