ECDIS User Guide
Alert Type
Rudder Angle
Sensor Rudder Angle Integrity VisionMaster FT
Unusable
Rudder Equipment
Sensor Rudder Equipment Data Integrity VisionMaster FT
Data Unusable
Safe Mode Activated
This node is currently running as a stand-alone node due to
network connectivity problems. The Connection Status menu
provides a 'Leave Safe Mode' button to restore normal network
communication, after the problem has been resolved.
Safety Depth Shallow
The chart's safety depth is set shallower than the ship's max draft.
Safety Height Low
The chart's safety height is set lower than the ship's height.
SC PCIO Comms
The SC PCIO communications has failed
Sensor Data Fault
Some sensor data is unusable or degraded. See the Sensor Status
menu (under System, Diagnostics) for more details.
Sensor Data Fix
The data used to fix a sensor is not corroborated with external
Uncorroborated
sensors.
Set and Drift Unusable
Sensor Set and Drift Integrity VisionMaster FT
Ship Overall Efficiency
Sensor Ship Overall Efficiency Corrected Integrity VisionMaster FT
Corrected Unusable
Ship Total Fuel
Sensor Ship Total Fuel Consumption Rate Value Integrity
Consumption Rate
VisionMaster FT
Unusable
Ship Total Power
Sensor Ship Total Power Integrity VisionMaster FT
Unusable
65900012
Description
Alerts
Priority
Notes
Alarm or
Depending on
Caution
configuration
Alarm or
Depending on
Caution
configuration
Warning
Caution
Caution
Warning
Caution
Caution
Alarm or
Depending on
Caution
configuration
Alarm or
Depending on
Caution
configuration
Alarm or
Depending on
Caution
configuration
Alarm or
Depending on
Caution
configuration
7-29
