Overview

ECDIS Common Features

The following table lists all the features common to ECDIS product types,
in addition to optional features that may be configured for your system.
Feature
Display controls
Display Features
Defining and displaying
user specified data
Scale selection
Range Rings
1-12
Additional details
Picture brilliance (day/night selection).
Brightness check
Displaying/hiding heading line and synthetics.
Centring and off-centring (MAX view) the
picture.
Display of primary, or primary and secondary
presentation displays (vertical/horizontal split
screen or popup window secondary display).
Hides all windows currently shown on the
display, or restore all previously opened
windows.
Zoom window defines a specific area of the
chart display to zoom into.
Display Chart – temporarily hides all synthetics
and displays only currently selected chart layer.
Display Base temporarily hides all synthetics
and displays only the chart base layer
A north arrow pointed true north in the upper left
corner of the chart window.
Scale and latitude bars drawn vertically 2 to 4
mm from the left border of the display.
Own ship's position.
Waypoint data.
Wind and depth data.
Scale ratio from 1:500 to 1:20,000,000
Range rings on or off. Ring interval dependant
on scale.
