3.3.8 Serial Port Setup
Select the
Port
entry from the
Serial port setup specifies communications parameters that the PM295 needs to
communicate with a master computer or a printer. The
menu operates the same as the
Appendix B lists all communications parameters with the corresponding labels and
applicable choices. For more information on communications operation, refer to
Chapter 5.
Port
Prot
ASCII
To change the setup parameter :
Ä Press
SELECT
Ä Scroll through applicable values with the up/down arrow keys until the desired
value appears.
Ä Press
ENTER
to return to the central window.
To quit the menu:
Ä From the central window, press
3.3.9 Discrete Input Setup
Select the
dinP
entry from the
The
DISCRETE INPUT SETUP
following illustrations:
Status
S.InP
inputs
1.1.1.1.
1.0.0.0.
Operating The PM295
MAIN
menu and press
BASIC SETUP
To select and view a setup parameter:
Ä From the central window, scroll through parameters with
the up/down arrow keys until the label of the desired
parameter appears. The parameter value will be indicated in
the lower window.
to choose the lower window.
ENTER to
MAIN
menu and press
menu consists of four sub-menus, as shown in the
Pulse
P.InP
inputs
0.0.0.0.
0.0.1.1.
ENTER
.
SERIAL PORT SETUP
menu (see above). Table B-3 in
return to the
MAIN
ENTER
.
Analog
An.SL
output
selector
0.0.0.0.
0.0.0.1.
menu.
External
E.Snc
synchro-
nization
pulse
0.0.0.0.
input
0.0.0.1.
39
