Table B-7 Setpoint Trigger Parameters
Group Parameter
label Label Name
hd.C2
L2 phase current harmonics
H01-H40 Harmonic H01-H40
hd.C3
L3 phase current harmonics
H01-H40 Harmonic H01-H40
hr.U1
L1/L12 phase harmonic voltages (odd harmonics)
H01-H39 Harmonic H01-H39
hr.U2
L2/L23 phase harmonic voltages (odd harmonics)
H01-H39 Harmonic H01-H39
hr.U3
L3 phase harmonic voltages (odd harmonics)
H01-H39 Harmonic H01-H39
hr.C1
L1 phase harmonic currents (odd harmonics)
H01-H39 Harmonic H01-H39
hr.C2
L2 phase harmonic currents (odd harmonics)
H01-H39 Harmonic H01-H39
hr.C3
L3 phase harmonic currents (odd harmonics)
H01-H39 Harmonic H01-H39
hr.Ac
Harmonic total kW (odd harmonics)
H01-H39 Harmonic H01-H39
hr.rE
Harmonic total kvar (odd harmonics)
H01-H39 Harmonic H01-H39
hr.PF
Harmonic total power factors (odd harmonics)
H01-H39 Harmonic H01-H39
Lo.Ph
New minimum real-time values per phase
U 1 Voltage L1/L12
U 2 Voltage L2/L23
U 3 Voltage L3/L31
cur1 Current L1
cur2 Current L2
cur3 Current L3
Ac.P1 kW L1
Ac.P2 kW L2
Ac.P3 kW L3
rE.P1 kvar L1
144
Range À
Unit
Á
% 0 to 100.00
% 0 to 100.00
V 0 to Vmax
V 0 to Vmax
V 0 to Vmax
A 0 to Imax
A 0 to Imax
A 0 to Imax
kW -Pmax to Pmax
kvar -Pmax to Pmax
n/a -1.00 to 1.00
Appendix B Programmable Parameters
Condition
label
GE/LE/Eq/nE
GE/LE/Eq/nE
GE/LE/Eq/nE
GE/LE/Eq/nE
GE/LE/Eq/nE
GE/LE/Eq/nE
GE/LE/Eq/nE
GE/LE/Eq/nE
GE/LE/Eq/nE
GE/LE/Eq/nE
GE/LE/Eq/nE
nEU
