Satec System 295 Installation And Operation Manual page 148

Table B-7 Setpoint Trigger Parameters
Group Parameter
label Label Name
th.C3 Current THD L3
HFc.1 K-Factor L1
HFc.2 K-Factor L2
HFc.3 K-Factor L3
rt.Lo
Real-time low values on any phase
U Low voltage
cur Low current
Ac.P Low kW
rE.P Low kvar
AP.P Low kVA
PF.LG Low power factor lag
PF.Ld Low power factor lead
thd.U Low voltage THD
thd.C Low current THD
HFc. Low K-Factor
rt.Hi
Real-time high values on any phase
U High voltage
cur High current
Ac.P High kW
rE.P High kvar
AP.P High kVA
PF.LG High power factor lag
PF.Ld High power factor lead
thd.U High voltage THD
thd.C High current THD
HFc. High K-Factor
rt.to
Real-time total values
Ac.P Total kW
rE.P Total kvar
AP.P Total kVA
PF Total PF
PF.LG Total PF Lag
PF.Ld Total PF Lead
rt.Au
Real-time auxiliary measurements
140
Range À
Unit
Á
% 0 to 100.0
1.0 to 999.9
1.0 to 999.9
1.0 to 999.9
V 0 to Vmax
A 0 to Imax
kW -Pmax to Pmax
kvar -Pmax to Pmax
kVA 0 to Pmax
0 to 1.00
0 to 1.00
% 0 to 100.0
% 0 to 100.0
1.0 to 999.9
V 0 to Vmax
A 0 to Imax
kW -Pmax to Pmax
kvar -Pmax to Pmax
kVA 0 to Pmax
0 to 1.00
0 to 1.00
% 0 to 100.0
% 0 to 100.0
1.0 to 999.9
kW -Pmax to Pmax
kvar -Pmax to Pmax
kVA 0 to Pmax
-1.00 to 1.00
0 to 1.00
0 to 1.00
Appendix B Programmable Parameters
Condition
label
GE/LE/Eq/nE
GE/LE/Eq/nE
GE/LE/Eq/nE
GE/LE/Eq/nE
