Table B-5 Pulsing Relay Outputs
Output Description
label
nonE Relay pulses disabled
Ac.Ei kWh imported
Ac.EE kWh exported
Ac.Et kWh total
rE.Ei kvarh imported
rE.EE kvarh exported
rE.Et kvarh total
AP.Et kVAh total
dint Demand interval pulse
tArF Tariff interval pulse
Table B-6 Setpoint Trigger Groups
Group label Description
nonE No trigger
SPEC Special inputs
uSr.E User event flags/manual control
int.E Internal events
t-r Timers
St.In Status inputs
PS.In Pulse inputs
rEL Relay status
Cnt Counters
Π
Time/date parameters
ti E
rt.Ph Real-time per phase measurements
rt.Lo Real-time low values on any phase
rt.Hi Real-time high values on any phase
rt.to Real-time three-phase total measurements
rt.Au Real-time auxiliary measurements
Ar.Ph Average per phase measurements
Ar.Lo Average low values on any phase
Ar.Hi Average high values on any phase
Ar.to Average three-phase total measurements
Ar.Au Average auxiliary measurements
136 Appendix B Programmable Parameters
