  • Page 1 PM290 Powermeter Installation and Operation Manual BG0208 Rev. A3...
  • Page 2 PM290 POWERMETER Installation and Operation Manual...
  • Page 3 LIMITED WARRANTY The manufacturer offers the customer an 24-month functional warranty on the instrument for faulty workmanship or parts from date of dispatch from the distributor. In all cases, this warranty is valid for 36 months from the date of production. This warranty is on a return to factory basis.
  • Page 4 The secondary of an external current transformer must never be allowed to be open circuit when the primary is energized. Ensure that the current transformer wiring is made through shorting switches and is secured using an external strain relief to reduce mechanical strain on the screw terminals, if necessary.

  • Page 5: Table Of Contents

    Table of Contents Quick Start................. iv 1 Introduction..............1 2 Installation and Interfaces ........... 4 Mechanical Installation............4 Electrical Installation ............6 3 Setup................14 Setup Procedure ..............14 Wiring Mode: CnF .............. 16 Potential Transformer Ratio: Pt.......... 17 Current Transformer: Ct............. 18 Maximum Power Demand Period: P........

  • Page 6: Quick Start

    Quick Start TYPICAL INSTALLATION...
  • Page 7 BASIC and COMMUNICATION PARAMETERS SETUP ∗ default setting) Code Parameter Options Description Wiring mode 3-wire open delta using 2 CTs 4-wire Wye using 3 PTs 3dir 3-wire direct connection using 2 CTs 4LL* 4-wire Wye using 3 PTs PT ratio 1.0∗...

  • Page 8: Introduction

    1 Introduction The PM290 is a 3-phase AC Powermeter specially designed to meet the needs of users ranging from electrical panel builders to substation operators. The PM290 performs all basic power measurements; Option L provides ground leakage current measurements (instead of external synchronization).
  • Page 9 Communications Connection (optional) Connection to a printer, computer or central control room is enabled by an RS-232/RS-422/RS-485 communications port that can operate at baud rates of up to 9,600 bps. The RS-422/RS-485 port can operate in multi-drop mode, permitting the connection of up to 32 instruments to a single communications line.
  • Page 10 Getting Started Connect the Powermeter to a suitable power supply. The Powermeter will initiate a series of self-tests. Upon completion of the self-tests, all of the front panel LEDs will light up for one second and indicate a one- digit diagnostic code. An ‘8’ represents normal power up. If a different diagnostic code constantly appears when you apply power to the instrument, contact your local distributor.

  • Page 11: Installation And Interfaces

    2 Installation and Interfaces 2.1 Mechanical Installation Figure 2-1 Front Panel Mounting (standard) Chapter 2 Installation and Interfaces...
  • Page 12 Figure 2-2 Rear Mounting Chapter 2 Installation and Interfaces...

  • Page 13: Electrical Installation

    2.2 Electrical Installation 2.2.1 Dip Switches Figure 2-3 Dip Switches (Rear View) Communications (see section 2.5): RS-232: switches 1-4 ON, switches 5-8 OFF; RS-422/RS-485: switches 1-4 OFF, switches 5-8 ON. Setup (see Chapter 3): switch 9 ON = enable, OFF = disable Page scrolling: switch 10 ON = stay at current page, OFF = return to page 1 after 30 seconds.
  • Page 14 If the instrument is installed in a harsh environment with potential for electromagnetic impulses from heavy switch gears, motors or lightning, then it is mandatory to use the EMI/RFI suppression cores provided with the instrument, connected to the power supply and communication terminals, as shown in Figure 2-4.
  • Page 15 2.2.4 Current Input Connections See Typical Installation on page iv for current input connections. All CTs must be connected in the correct order and with the correct polarity as shown in the wiring diagrams for the instrument to operate properly. If the instrument displays a power factor of zero or close to it, or if power readings show unreasonable values, this may indicate a reversal of polarity of the CT connections.
  • Page 16 LINE 1(A) LINE 2(B) LOAD LINE 3(C) Shorting Switche s Currents Vo ltage s c99-0 2015 Figure 2-5 3-wire Direct Connection Using 2 CTs - Wiring Mode 3dir LINE 1(A) LINE 2(B) LOAD LINE 3(C) Shorting Switche s Curre nts Vo ltage s 99-02016 Figure 2-6 3-Wire Open Delta Connection Using 2 PTs, 2 CTs -...
  • Page 17 LINE 1(A) LINE 2(B) LOAD LINE 3(C) Shortin g Switche s Currents Voltages c99-02018 Figure 2-7 4-Wire Wye Direct Connection Using 3 CTs - Wiring Mode 4L-n/4L-L LINE 1(A) LINE 2(B) LOAD LINE 3(C) Shorting Switc hes Currents Vo ltage s c99-02019 Figure 2-8 4-wire Wye Connection Using 3 PTs, 3 CTs - Wiring Mode 4L-n/4L-L...
  • Page 18 LINE 1 240VA C LINE 2 120 V AC 240V A C LOAD 240VAC 208VA C LINE 3 120 VAC Shorting Swit ches Power Transformer delta connection 240V 240V 120V 120V VOLTAGES DISPLAYED: 2. Line to line voltages: 240V; 240V; 240V. 01-01012 Figure 2-9 4-wire Grounded Delta Connection Using 3 CTs - Wiring Mode 4L-n/4L-L...
  • Page 19 2.2.8 Analog Output The Analog Output requires a galvanically isolated external power supply. See Figure 2-11 for connections: negative to terminal 15 and positive to terminal 16. In certain industrial applications, a circuit may be required to protect against accidental shorts. FUSE To terminal #16 To terminal #15...
  • Page 20 2.2.10 Ground Leakage (Option L) Ground leakage connection is at terminals 26 and 27. 26 27 13 14 SHORTING 1-200 1-200 SWITCH KVARH AC or DC GROUND LEAKAGE POWER SUPPLY CURRENT TRANSFORM ANALOG OUTPUT 01-01009-2 Figure 2-12 Ground Leakage Current Transformer Connection Chapter 2 Installation and Interfaces...

  • Page 21: Setup

    3 Setup NOTE: Setup is performed after installation is completed. 3.1 Setup Procedure To enable setup, turn OFF Dip Switch 9 on SW2 located at the top left of the rear of the instrument (see Figure 2-3). When the switch is down it is OFF.
  • Page 22 3.1.2 Changing Parameter Values Press SELECT again and the dot beside the parameter code will disappear. CURRENT V OLTAGE MAX. AMP CURRENT V OLTAGE CnF. MAX. AMP V OLTAGE CURRENT MAX AMP Use the ⇑ ⇓ keys to scroll to the desired value. When the setup parameter is correctly defined, press on the RESET key and the dot will re-appear.

  • Page 23: Wiring Mode: Cnf

    3.2 Wiring Mode: CnF Choose from 4 wiring modes: 1) 3dir 3-wire direct connection using 2 CTs 2) 3OP 3-wire open delta connection using 2 PTs, 2 CTs 3) 4L-n 4-wire direct or WYE or grounded delta connection using 3 CTs, with or without PTs, using line-to-neutral values 4) 4L-L 4-wire direct or WYE or grounded delta connection using 3 CTs, with or without PTs, using line-to-line...

  • Page 24: Potential Transformer Ratio: Pt

    3.3 Potential Transformer Ratio: Pt Note: Pt must be defined before relay setpoint definition. In a direct connection, at low voltage (up to 660V), the PT must be set to 1. In the case of connection using PTs, the PT ratio must be calculated.

  • Page 25: Current Transformer: Ct

    3.4 Current Transformer Primary Current: Ct Notes: 1) Ct must be defined before relay setpoint definition. 2) For Option L, ground leakage primary current is represented by Ct.G This parameter defines the primary value of the Current Transformer. - Press SELECT; the dot will disappear. - Use the ⇑...

  • Page 26: Maximum Ampere Demand Period: Ap

    3.6 Ampere Demand Period: AP This parameter defines the time period over which average ampere demand is calculated. - Press SELECT; the dot will disappear. - Use the ⇑ ⇓ keys to scroll to the appropriate value (0 - 1800 seconds;...

  • Page 27: Memory Buffer: Buf

    3.7 Memory Buffer: buF This parameter defines the number of measurements which will serve as the basis for calculating average values of voltage, current and power. - Press SELECT; the dot will disappear. - Use the ⇑ ⇓ keys to scroll to the appropriate value: nor (normal) = 8 (for stable voltage and current situations) unSt (unstable) = 32 (for unstable voltage and current situations.

  • Page 28: Baud Rate: Br

    (see Section 3.12). - Press SELECT; the dot will disappear. - Use the ⇑ ⇓ keys to scroll to the appropriate value: *The PM290 ASCII protocol: 0 - 32 Modbus protocol: 1* - 247 will accept a - Press RESET;...

  • Page 29: Handshake Mode: H.sh

    3.11 Handshake Mode: H.Sh Handshaking refers to a signal from the receiving device indicating its readiness to receive data. Handshaking is achieved by means of either hardware signals or software commands. - Press SELECT; the dot will disappear. - Use the ⇑ ⇓ keys to scroll to the appropriate value: sOFt or Hard - Press RESET;...

  • Page 30: Relays

    3.13 Relays There are 4 relays in the instrument which can be associated with up to 8 setpoints. Three of the relays may also be used for pulsing (see following page). The setpoint values appear in the following windows (each window has its number marked above it in the illustration below): Window Setpoint Unit...
  • Page 31 - Press SELECT; the dot after the relay number will disappear. Window 5 will display 'on'. This allows the user to set or change the value at which the setpoint is activated. The 'High Voltage' setpoint value (or dots) will appear in window 1; the other windows will be empty. - Use the ⇑...

  • Page 32: Analog Output: A (Optional)

    3.14 Analog Output: A (optional) Up to 12 parameters may be assigned an analog output: Windo Parameter Name Description Voltage L1 / L12 Voltage L2 / L23 Voltage L3 / L31 Current L1 Current L2 Current L3 Power Factor 8 (right) Ac.d Active Power Accumulated Demand...
  • Page 33 Note: If you are not using an AX-8 Analog Expander, cancel all analog output assignments so as not to disrupt communication. The following table gives the range of values of the output parameters: Parameter Value 4-20mA 0-20mA Note Voltage 4 mA 0 mA No PT 660V...
  • Page 34 Parameters measured by the PM290 are calculated based on the analog output current (I ), as per the following table: Analog Measured Output 4-20mA Output 0-20mA Parameter Voltage, V V = (I V = I Analog Full Scale Analog Full Scale...

  • Page 35: Data Display

    4 Data Display In the monitoring mode, values are displayed on 3 pages. Use the ⇓ key to scroll through the pages. The display will return to page 1 after 30 seconds. For resolution and parameter ranges, see Appendix A, Measurement Specifications.

  • Page 36: Self-Test Diagnostics

    4.2 Self-Test Diagnostics The PM290 periodically perform self-test diagnostics. If the instrument fails the self-test diagnostics, it discards the last measurement results, and an error code (from 1 to 7) is displayed for 2 seconds on all LEDs. Code 8 represents Power Down (Normal).

  • Page 37: Appendix A: Technical Specifications

    Appendix A: Technical Specifications Input and Output Ratings 3 galvanically 120 V INPUT USING PT (up to 120+20% V line-to- isolated voltage line voltage) (Option inputs Burden: < 0.015 VA 660 V DIRECT INPUT (up to 660 V line-to-line voltage or up to 550 V line-to-neutral voltage) Burden: <...
  • Page 38 Input and Output Ratings Voltage and Standard 9.52 mm pitch (UL recognized) current input Screw M 3 terminals Maximum wire diameter 2.591 mm (10 AWG) Service Standard 5 mm pitch (UL recognized XCFR2) terminals Screw M2.6 Maximum wire diameter 2 mm (12 AWG) Display High-brightness seven-segment digital LEDs, 11 windows.
  • Page 39 Measurement Specifications Resolution @ range Parameter, units Full scale Accuracy, % Range Conditions Front panel display Comm. 1 V @ 1 to 999 V Voltage, V × 10% to 120% 0 to 999,000 0.25 For Ln 120V PT @ reading and ≤1% @ 1,000 to 999,000 V 120V for 3OP...
  • Page 40 Measurement Specifications Resolution @ range Parameter, units Full scale Accuracy, % Range Conditions Front panel display Comm. Power factor |PF| ≥ 0.5 -0.99 to +1.00 0.01 0.01 1 A @ 1 to 999 A Unbalanced (neutral) CT primary current 2% to 120% 0 to 60,000 A current, A ≤1% @ 1,000 to 60,000 A...
  • Page 41 Key: PT - external potential transformer ratio CT, CT primary current - the primary current rating of the external current transformer @ 10% to 120 % of voltage full scale and 2% to 120 % of current full scale NOTES 1.

  • Page 42: Appendix B: Communication Cable Drawings

    9-pin Computer Connector, Software Handshake DB9 male DB9 female connector connector To IBM To PM290 PC/Compatible Note: For hardware handshake, connect to pins 4, 5; do not short between pins 6 and 4. Printer Connector - Example DB 9 male...
  • Page 43 RS-422 25-pin Computer Connector DB9 male DB25 female connector connector To PM290 TxD- RxD- TxD- RxD- To IBM PC/Compatible RTS- To PM290 CTS- TxD- RxD- To PM290 TxD- RxD- RS-422 25 pin 9-pin Computer Connector DB9 male DB25 female connector...
  • Page 44 RS-485 25-pin Computer Connector DB9 male DB25 female connector connector To PM290 TxD- RxD- RxD- TxD- IBM PC/Compatible RTS- To PM290 CTS- TxD- RxD- To PM290 TxD- RxD- RS-485 25 pin 9-pin Computer Connector DB9 male DB25 female connector connector...
