3.3.5 Entering the Password

The
PASSWORD
protected level while password protection enabled. If you enter an incorrect
password, you will return to the previous menu.
The upper menu window is a static menu label. A password is entered into the
second edit-window. A password is four digits long. Each digit in the password
window can be selected individually. When you enter the
first password digit is currently accessible.
PASS
0000

3.3.6 Selecting the Setup Group

The setup parameters are organized into 13 groups accessed via primary menus. The
user enters a setup primary menu from the
The MAIN menu consists of two button-windows. The upper window displays a list
of the primary menu entries. For the entire list of the setup menus and menu labels,
refer to a map shown in Figure 3.2. The lower labeled button-window allows the
user to return to the previous menu.
bASc
ESC
To quit the main menu:
Ä Press
SELECT
Ä Press
.
ENTER
Operating The PM295
menu appears when you enter the programming mode at the
To enter a password:
Ä Set the first digit with the up/down arrow keys.
Ä Press
SELECT
Ä Set the second digit with the up/down arrow keys.
Ä In the same manner, set the other password digits.
Ä Press
ENTER .
To select a setup group:
Ä Ensure that the upper window is currently active (it must
flash). If it is not, press
Ä Scroll through menu entries with the up/down arrow keys
until the label of the desired setup group appears.
Ä Press
.
ENTER
to choose the ESC window.
to advance to the next digit.
menu shown below.
MAIN
.
SELECT
menu, the
PASSWORD
