Satec System 295 Installation And Operation Manual page 149

Table B-7 Setpoint Trigger Parameters
Group Parameter
label Label Name
Au.C Auxiliary current
nEU.C Neutral current
Frequency Â
FrEq
U.Unb Voltage unbalance
C.Unb Current unbalance
Ar.Ph
Average values per phase
U 1 Voltage L1/L12
U 2 Voltage L2/L23
U 3 Voltage L3/L31
cur1 Current L1
cur2 Current L2
cur3 Current L3
Ac.P1 kW L1
Ac.P2 kW L2
Ac.P3 kW L3
rE.P1 kvar L1
rE.P2 kvar L2
rE.P3 kvar L3
AP.P1 kVA L1
AP.P2 kVA L2
AP.P3 kVA L3
PF1 Power factor L1
PF2 Power factor L2
PF3 Power factor L3
th.U1 Voltage THD L1/L12
th.U2 Voltage THD L2/L23
th.U3 Voltage THD L3
th.C1 Current THD L1
th.C2 Current THD L2
th.C3 Current THD L3
HFc.1 K-Factor L1
HFc.2 K-Factor L2
HFc.3 K-Factor L3
Appendix B Programmable Parameters
Range À
Unit
Á
mA/A 0 to Iaux max
A 0 to Imax
Hz 0 to 100.0
% 0 to 300
% 0 to 300
V 0 to Vmax
V 0 to Vmax
V 0 to Vmax
A 0 to Imax
A 0 to Imax
A 0 to Imax
kW -Pmax to Pmax
kW -Pmax to Pmax
kW -Pmax to Pmax
kvar -Pmax to Pmax
kvar -Pmax to Pmax
kvar -Pmax to Pmax
kVA 0 to Pmax
kVA 0 to Pmax
kVA 0 to Pmax
-1.00 to 1.00
-1.00 to 1.00
-1.00 to 1.00
% 0 to 100.0
% 0 to 100.0
% 0 to 100.0
% 0 to 100.0
% 0 to 100.0
% 0 to 100.0
1.0 to 999.9
1.0 to 999.9
1.0 to 999.9
Condition
label
GE/LE/Eq/nE
