Table B-4b Analog Output Parameters
Parameter
Group Code
rE.P1 kvar L1
rE.P2 kvar L2
rE.P3 kvar L3
AP.P1 kVA L1
AP.P2 kVA L2
AP.P3 kVA L3
PF1 Power factor L1
PF2 Power factor L2
PF3 Power factor L3
th.U1 Voltage THD L1/L12
th.U2 Voltage THD L2/L23
th.U3 Voltage THD L3
th.C1 Current THD L1
th.C2 Current THD L2
th.C3 Current THD L3
HFc.1 K-Factor L1
HFc.2 K-Factor L2
HFc.3 K-Factor L3
rt.to
Real-time total values
Ac.P Total kW
rE.P Total kvar
AP.P Total kVA
PF Total PF
PF.LG Total PF Lag
PF.Ld Total PF Lead
rt.Au
Real-time auxiliary measurements
Au.C Auxiliary current
nEU.C Neutral current
Frequency Â
FrEq
U.Unb Voltage unbalance
C.Unb Current unbalance
Ar.Ph
Average values per phase
U 1 Voltage L1/L12
132
Unit
Name
kvar
kvar
kvar
kVA
kVA
kVA
n/a
n/a
n/a
%
%
%
%
%
%
n/a
n/a
n/a
kW
kvar
kVA
n/a
n/a
n/a
mA/A
A
Hz
%
%
V
Appendix B Programmable Parameters
Range/scale À
Á
Zero
-Pmax Pmax
-Pmax Pmax
-Pmax Pmax
0 Pmax
0 Pmax
0 Pmax
-1.00 1.00
-1.00 1.00
-1.00 1.00
0 100.0
0 100.0
0 100.0
0 100.0
0 100.0
0 100.0
1.0 999.9
1.0 999.9
1.0 999.9
-Pmax Pmax
-Pmax Pmax
0 Pmax
-1.00 1.00
0 1.00
0 1.00
0 Iaux max
0 Imax
0 100.0
0 300
0 300
0 Vmax
Full
