Table B-6 Setpoint Trigger Groups
Group label Description
dnd Present demands
hd.U1 L1/L12 phase voltage harmonics
hd.U2 L2/L23 phase voltage harmonics
hd.U3 L3 phase voltage harmonics
hd.C1 L1 phase current harmonics
hd.C2 L2 phase current harmonics
hd.C3 L3 phase current harmonics
hr.U1 L1/L12 phase harmonic voltages (odd harmonics)
hr.U2 L2/L23 phase harmonic voltages (odd harmonics)
hr.U3 L3 phase harmonic voltages (odd harmonics)
hr.C1 L1 phase harmonic currents (odd harmonics)
hr.C2 L2 phase harmonic currents (odd harmonics)
hr.C3 L3 phase harmonic currents (odd harmonics)
hr.Ac Harmonic total active powers (odd harmonics)
hr.rE Harmonic total reactive powers (odd harmonics)
hr.PF Harmonic total power factors (odd harmonics)
Lo.Ph New minimum real-time values per phase
Lo.to New minimum real-time total values
Lo.Au New minimum real-time auxiliary values
Lo.dn New minimum demands
Lo.PG New programmable Min/Max minimum log
Hi.Ph New maximum real-time values per phase
Hi.to New maximum real-time total values
Hi.Au New maximum real-time auxiliary values
Hi.dn New maximum demands
Hi.PG New programmable Min/Max maximum log
tOU TOU system parameters
Lt.Ac New TOU minimum kW demands
Lt.rE New TOU minimum kvar demands
Lt.AP New TOU minimum kVA demands
Ht.Ac New TOU maximum kW demands
Ht.rE New TOU maximum kvar demands
Ht.AP New TOU maximum kVA demands
