Satec System 295 Installation And Operation Manual page 142

Table B-4b Analog Output Parameters
Parameter
Group Code
PF.Ld Total PF Lead
Ar.Au
Average auxiliary measurements
Au.C Auxiliary current
nEU.C Neutral current
Frequency Â
FrEq
U.Unb Voltage unbalance
C.Unb Current unbalance
dnd
Present demands
Ud. 1 Volt demand L1
Ud. 2 Volt demand L2
Ud. 3 Volt demand L3
Ad. 1 Ampere demand L1
Ad. 2 Ampere demand L2
Ad. 3 Ampere demand L3
Ac.bd Block kW demand (import)
rE.bd Block kvar demand (total)
AP.bd Block kVA demand
Ac.Sd Sliding window kW demand
(import)
rE.Sd Sliding window kvar demand
(total)
AP.Sd Sliding window kVA demand
Ac.td Thermal kW demand (import)
rE.td Thermal kvar demand (total)
AP.td Thermal kVA demand
Ac.Ad Accumulated kW demand
(import)
rE.Ad Accumulated kvar demand
(total)
AP.Ad Accumulated kVA demand
Ac.Pd Predicted kW demand (import)
rE.Pd Predicted kvar demand (total)
AP.Pd Predicted kVA demand
hr.U1
L1/L12 phase harmonic voltages (odd harmonics)
134
Unit
Name
n/a
mA/A
A
Hz
%
%
V
V
V
A
A
A
kW
kvar
kVA
kW
kvar
kVA
kW
kvar
kVA
kW
kvar
kVA
kW
kvar
kVA
Appendix B Programmable Parameters
Range/scale À
Á
Zero
0 1.00
0 Iaux max
0 Imax
0 100.0
0 300
0 300
0 Vmax
0 Vmax
0 Vmax
0 Imax
0 Imax
0 Imax
0 Pmax
0 Pmax
0 Pmax
0 Pmax
0 Pmax
0 Pmax
0 Pmax
0 Pmax
0 Pmax
0 Pmax
0 Pmax
0 Pmax
0 Pmax
0 Pmax
0 Pmax
Full
