Satec System 295 Installation And Operation Manual page 139

Table B-4a Analog Output Groups
Code
nonE Analog output channel disabled
rt.Ph Real-time per phase measurements
rt.to Real-time three-phase total measurements
rt.Au Real-time auxiliary measurements
Ar.Ph Average per phase measurements
Ar.to Average three-phase total values
Ar.Au Average auxiliary measurements
dnd Present demands
hr.U1 L1/L12 phase harmonic voltages (odd harmonics)
hr.U2 L2/L23 phase harmonic voltages (odd harmonics)
hr.U3 L3 phase harmonic voltages (odd harmonics)
hr.C1 L1 phase harmonic currents (odd harmonics)
hr.C2 L2 phase harmonic currents (odd harmonics)
hr.C3 L3 phase harmonic currents (odd harmonics)
hr.Ac Harmonic total active powers (odd harmonics)
hr.rE Harmonic total reactive powers (odd harmonics)
hr.PF Harmonic total power factors (odd harmonics)
Table B-4b Analog Output Parameters
Group Code
nonE nonE
rt.Ph
U 1
U 2
U 3
cur1
cur2
cur3
Ac.P1
Ac.P2
Ac.P3
Appendix B Programmable Parameters
Parameter
Name
Output channel disabled
Real-time values per phase
Voltage L1/L12
Voltage L2/L23
Voltage L3/L31
Current L1
Current L2
Current L3
kW L1
kW L2
kW L3
Description
Unit
Á
n/a
V
V
V
A
A
A
kW
kW
kW
Range/scale À
Zero Full
0 0
0 Vmax
0 Vmax
0 Vmax
0 Imax
0 Imax
0 Imax
-Pmax Pmax
-Pmax Pmax
-Pmax Pmax
