Satec System 295 Installation And Operation Manual page 154

Table B-7 Setpoint Trigger Parameters
Group Parameter
label Label Name
Ud. 3 Volt demand L3
Ad. 1 Ampere demand L1
Ad. 2 Ampere demand L2
Ad. 3 Ampere demand L3
Ac.bd Block kW demand
rE.bd Block kvar demand
AP.bd Block kVA demand
Ac.Sd Sliding window kW demand
rE.Sd Sliding window kvar demand
AP.Sd Sliding window kVA
demand
Ac.td Thermal kW demand
rE.td Thermal kvar demand
AP.td Thermal kVA demand
Lo.PG
Programmable Min/Max minimum registers
rG.01- Programmable Min/Max
rG.16 register #1 - #16
Hi.Ph
New maximum real-time values per phase
U 1 Voltage L1/L12
U 2 Voltage L2/L23
U 3 Voltage L3/L31
cur1 Current L1
cur2 Current L2
cur3 Current L3
Ac.P1 kW L1
Ac.P2 kW L2
Ac.P3 kW L3
rE.P1 kvar L1
rE.P2 kvar L2
rE.P3 kvar L3
AP.P1 kVA L1
AP.P2 kVA L2
AP.P3 kVA L3
Power factor L1 Ä
PF1
Power factor L2 Ä
PF2
146
Range À
Unit
Á
Appendix B Programmable Parameters
Condition
label
nEU
nEU
