17
SET MODE

Tone Control Set mode

RX HPF/LPF
Tone Control > RX > (Mode) > RX HPF/LPF (RX HPF/
LPF)
(Mode: SSB/CW/RTTY/AM/FM/DV)
First select the operating mode, then set the receive
audio high-pass fi lter to between 100 Hz and 2000 Hz
in 100 Hz steps.
RX HPF/LPF
Tone Control > RX > (Mode) > RX HPF/LPF (RX HPF/
LPF)
(Mode: SSB/CW/RTTY/AM/FM/DV)
First select the operating mode, then set the receive
audio low-pass fi lter to between 500 Hz and 2400 Hz
in 100 Hz steps.
RX Bass
Tone Control > RX > (Mode) > RX Bass (RX Bass)
(Mode: SSB/AM/FM/WFM/DV)
First select the operating mode, then set the receive
audio bass level to between –5 and +5.
RX Treble
Tone Control > RX > (Mode) > RX Treble (RX Treble)
(Mode: SSB/AM/FM/WFM/DV)
First select the operating mode, then set the receive
audio treble level to between –5 and +5.
TX Bass
Tone Control > TX > (Mode) > TX Bass (TX Bass)
(Mode: SSB/AM/FM/DV)
First select the operating mode, then set the transmit
audio bass level to between –5 and +5.
TX Treble
Tone Control > TX > (Mode) > TX Treble (TX Treble)
(Mode: SSB/AM/FM/DV)
First select the operating mode, then set the transmit
audio treble level to between –5 and +5.
(Default: [----] - ----)
(Default: ---- - [----])
(Default: 0)
(Default: 0)
(Default: 0)
(Default: 0)
17-23
TBW (WIDE)
Tone Control > TX > SSB > TBW (WIDE) (TBW
(WIDE))
(Mode: SSB)
Set the lower and higher cut-off frequencies of the
transmission passband width for your wide setting.
• Lower: 100, 200, 300 or 500 Hz
• Higher: 2500, 2700, 2800 or 2900 Hz
TBW (MID)
Tone Control > TX > SSB > TBW (MID) (TBW (MID))
(Mode: SSB)
Set the lower and higher cut-off frequencies of the
transmission passband width for your middle setting.
• Lower: 100, 200, 300 or 500 Hz
• Higher: 2500, 2700, 2800 or 2900 Hz
TBW (NAR)
Tone Control > TX > SSB > TBW (NAR) (TBW (NAR))
(Mode: SSB)
Set the lower and higher cut-off frequencies of the
transmission passband width for your narrow setting.
• Lower: 100, 200, 300 or 500 Hz
• Higher: 2500, 2700, 2800 or 2900 Hz
(Default: 100 - 2900)
(Default: 300 - 2700)
(Default: 500 - 2500)
