FUNCTIONS FOR TRANSMIT
Measuring SWR (Continued)
D
SWR Graph Set mode
q
Push (C) one or more times to select the
MENU
"M-3" screen (M-3 menu).
w D) to display the "SWR" (SWR Graph)
Touch [SWR](
screen.
e D) to enter the "SWR GRAPH SET"
Touch [SET](
screen.
r
Touch the desired item to select.
• See below for details of the set items and options.
t
Touch the desired option to change the setting.
• If desired, touch the item for 1 second to open the De-
fault set window, then select the "Default" to reset to the
default setting.
y 2](D) or push
Touch [
"SWR" (SWR Graph) screen.
u
Push (C) to return to the "M-3" screen
MENU
(Menu 3).
Number of Graph Bar
Select the number of the graph bar for the displayed
SWR Graph.
• The selectable number are 3, 5, 7, 9, 11 and 13.
Measuring Step
Select the SWR measuring step for the center frequen-
cy.
• The selectable steps are 10k, 50k, 100k and 500
kHz.
(C) to return to the
MENU
(Default: 5)
(Default: 10k)
L eft D isplay
C enter
6-16
The L, R, C or D in the
R ight
instructions indicate the
part of the controller.
L: Left side
R: Right side
C: Center bottom
D: Display (Touch panel)
Push MENU
Touch [SWR]
Touch [SET]
Touch the item
