17
SET MODE
Set mode items and Default settings (Continued)
NOTE: The default settings shown below in bold are for the USA version.
The default settings may differ, depending on your transceiver version.
Function
Monitor
Monitor Level
Beep Level
Beep Level Limit
Beep (Confi rmation)
Band Edge Beep
User Band Edge
RF/SQL Control
TX Delay
HF
50M
144M
430M
Time-Out Timer
PTT Lock
SPLIT/DUP
Quick SPLIT
SPLIT Offset
SPLIT LOCK
DUP Offset
One Touch Repeater
Auto Repeater
In this item, set the function options.
OFF or ON
0%~50%~100%
0%~50%~100%
OFF or ON
OFF or ON
OFF, ON (Default), ON (User) or ON
(User) & TX Limit
1: 1.800.000–1.999.999
2: 3.500.000–3.999.999
3: 7.000.000–7.300.000
4: 10.100.000–10.150.000
5: 14.000.000–14.350.000
6: 18.068.000–18.168.000
7: 21.000.000–21.450.000
8: 24.890.000–24.990.000
9: 28.000.000–29.700.000
10: 50.000.000–54.000.000
11: 144.000.000–146.000.000
12: 430.000.000–440.000.000
13~30: (blank)
Auto, SQL or RF+SQL
OFF, 10ms, 15ms, 20ms, 25ms or
30ms
OFF, 10ms, 15ms, 20ms, 25ms or
30ms
OFF, 10ms, 15ms, 20ms, 25ms or
30ms
OFF, 10ms, 15ms, 20ms, 25ms or
30ms
OFF, 3min, 5min, 10min, 20min or
30min
OFF or ON
OFF or ON
–9.999 MHz~0.000 MHz~+9.999 MHz Sets the frequency offset for the Split function.
OFF or ON
0.0000 MHz~9.9999 MHz
( The default value may differ, depend-
ing on the frequency band and the
transceiver version.)
DUP– or DUP+
OFF, ON (DUP) or ON (DUP,TONE)
17-5
Selects whether or not to monitor your transmit
signal in any mode other than CW.
Sets the monitor level.
Sets the beep output level.
Selects whether or not to limit the volume to the
specifi ed level, and further rotation of the [AF]
control will not increase the level.
Turns the confi rmation beep tones ON or OFF.
Selects whether or not to sound a beep when you
tune outside of, or back into the amateur band's
frequency range.
Selects the user band frequency range to sound
a beep when the Band Edge Beep function is
set to "ON (User)" or "ON (User) & TX Limit," and
you tune outside of, or back into a programmed
range.
Select the function of the [RF/SQL] control.
Sets the transmission's timing of the IC-7100 to
prevent any external equipment that is connected
from damage by the refl ected wave.
Sets the transmission's timing of the IC-7100 to
prevent any external equipment that is connected
from damage by the refl ected wave.
Sets the transmission's timing of the IC-7100 to
prevent any external equipment that is connected
from damage by the refl ected wave.
Sets the transmission's timing of the IC-7100 to
prevent any external equipment that is connected
from damage by the refl ected wave.
Selects the Time-Out Timer time options to pre-
vent an accidental prolonged transmission.
Selects whether or not to inhibit transmission.
Turns the Quick SPLIT function ON or OFF.
Turns the SPLIT LOCK function ON or OFF.
Sets the frequency offset for repeater operation.
Selects the duplex direction for the One Touch
Repeater function.
Turns the Auto Repeater function ON or OFF.
