17
SET MODE
Function Set mode (Continued)
MAIN DIAL Auto TS
Function > MAIN DIAL Auto TS (MAIN DIAL Auto TS)
Set the Auto Tuning Step function for the Dial.
When rapidly rotating the Dial, the tuning step auto-
matically changes as selected.
There are two types of auto tuning steps: LOW (Faster)
and HIGH (Fastest).
• OFF: Auto tuning step is turned OFF.
• LOW: Approximately 2 times faster.
• HIGH: Approximately 5 times faster when the tuning
step is set to 1 kHz or smaller steps; approxi-
mately 2 times faster when the tuning step is
set to 5 kHz or larger steps.
MIC Up/Down Speed
Function > MIC Up/Down Speed (MIC Up/Down
Speed)
Set the rate at which frequencies are tuned while hold-
ing down the microphone [∫]/[√] switches.
• Slow: Low speed (25 tuning steps/second)
• Fast: High speed (50 tuning steps/second)
[NOTCH] Switch (SSB)
Function > [NOTCH] Switch (SSB) ([NOTCH] Switch
(SSB))
Select the Auto, Manual or Auto/Manual notch fi lter to
be used for SSB mode operation.
• Auto: Only the Auto notch fi lter can be used.
• Manual: Only the Manual notch fi lter can be
used.
• Auto/Manual: Both the Auto and Manual notch fi lters
can be used.
[NOTCH] Switch (AM)
Function > [NOTCH] Switch (AM) ([NOTCH] Switch
(AM))
Select the Auto, Manual or Auto/Manual notch fi lter to
be used for AM mode operation.
• Auto: Only the Auto notch fi lter can be used.
• Manual: Only the Manual notch fi lter can be
used.
• Auto/Manual: Both the Auto and Manual notch fi lters
can be used.
(Default: HIGH)
(Default: Fast)
(Default: Auto/Manual)
(Default: Auto/Manual)
17-21
SSB/CW Sync Tuning
Function > SSB/CW Sync Tuning (SSB/CW Sync Tun-
ing)
Turn the displayed frequency shift function ON or OFF.
When this function is turned ON, the audio pitch or
tones of the received signal will remain the same, even
when the operating mode is changed between SSB
and CW.
The amount of frequency shift may differ, depending on
the CW pitch setting.
• OFF: The displayed frequency does not shift.
• ON: The displayed frequency shifts when the operat-
ing mode is changed between SSB and CW.
CW Normal Side
Function > CW Normal Side (CW Normal Side)
Select the sideband used to receive CW in the CW nor-
mal mode between LSB and USB.
VOICE 1st Menu
Function > VOICE 1st Menu (VOICE 1st Menu)
Select VOICE-Root or VOICE-TX as the menu that ap-
pears fi rst after touching [VOICE] in the "M2" screen
(Menu 2), when the SSV, AM, FM or DV mode is se-
lected.
• VOICE-Root: The voice menu appears fi rst.
• VOICE-TX: The voice SEND menu appears fi rst.
KEYER 1st Menu
Function > KEYER 1st Menu (KEYER 1st Menu)
Select KEYER-Root or KEYER-SEND as the menu
that appears fi rst after touching [KEYER] in the "M2"
screen (Menu 2), when in the CW mode.
• KEYER-Root: The Memory keyer menu appears
fi rst.
• KEYER-SEND: The Keyer SEND menu appears fi rst.
Speaker Out
Function > Speaker Out (Speaker Out)
Select the speaker output function.
• OFF: The speaker does not output the received au-
dio.
The [ACC] socket, [USB] port, and [MIC] con-
nector output the received audio.
• ON: The speaker outputs the received audio.
(Default: OFF)
(Default: LSB)
(Default: VOICE-TX)
(Default: KEYER-SEND)
(Default: ON)
