Appendix A: Schematics

Power Supply Decoupling

IC10PWR represents the various voltage supply inputs to the FPGA and shows the power
decoupling network.
Jumper JP9 defines the voltage applied to VCCO on I/O Bank 0. The default setting is 3.3V.
See
additional details.
146
"Voltage Control," page 22
www.xilinx.com
and "Voltage Supplies to the Connector," page 114
Spartan-3E Start Kit Board User Guide
R
for
UG230 (v1.0) March 9, 2006
