IM 308-C master interface and memory card
3.4

Installing the memory card

Purpose of the
memory card
Changing the
memory card
3-10
The memory card is used to store the following data:
Configuration data generated with COM ET 200 Windows,
or
The operating system to be imported to the IM 308-C.
If you want to change the memory card, proceed as follows:
1. Set the mode selector switch on the IM 308-C to "ST".
2. Switch off the power supply to the IM 308-C.
3. Pull the memory card.
4. Insert the new memory card.
5. Switch on the power supply to the IM 308-C.
ET 200 Distributed I/O System
EWA 4NEB 780 6000-02a
