Draytek Vigor2926L User Manual page 927

preamble [enable]
preamble show
ssid[ssid_num enable
ssid_name]
ssid hide [ssid_num enab le]
ssid show
ratectl [ssid_num enable
upload download]
ratectl show
isolate lan [ssid_num
enable]
isolate member [ssid_num
enable]
isolate vpn [ssid_num
enable]
isolate show
E x a m p l
E x a m p
> wl_dual config mode 11a
Current mode is 11a
% <Note> Please restart 5G wireless after you set the channel
> wl_dual config channel 60
Current channel is 60
% <Note> Please restart 5G wireless after you set the channel.
Vigor2926 Series User's Guide
It means to define the length of the sync field in an 802.11 packet.
Most modern wireless network uses short preamble with 56 bit sync
field instead of long preamble with 128 bit sync field. However,
some original 11b wireless network devices only support long
preamble.
0: disable to use long preamble.
1: enable to use long preamble.
It means to display if preamble is enabled or not.
It means to set the name of the SSID, hide the SSID if required.
ssid_num: Type 1, 2, 3 or 4 to specify SSID1, SSID2, SSID3 or SSID4.
ssid_name: Give a name for the specified SSID.
It means to hide the name of the SSID if required.
ssid_num: Type 1, 2, 3 or 4 to specify SSID1, SSID2, SSID3 or SSID4.
enable: Type 0 to hide the SSID or 1 to display the SSID.
It means to display a table of SSID configuration.
It means to set the rate control for the specified SSID.
ssid_num: Choose 1, 2, 3 or 4 to specify SSID1, SSID2, SSID3 or SSID4.
enable: It means to enable the function of the rate control for the
specified SSID. 0: disable and 1:enable.
upload: It means to configure the rate control for data upload. The
unit is kbps.
download: It means to configure the rate control for data
download. The unit is kbps.
(example:
It means to display the data transmission rate (upload and
download) for SSID1, SSID2, SSID3 and SSID4.
It means to isolate the wireless connection from LAN.
It can make the wireless clients (stations) with remote-dial and LAN
to LAN users not accessing for each other.
ssid_num: Choose 1, 2, 3 or 4 to specify SSID1, SSID2, SSID3 or SSID4.
enable: It means to enable such function.
It means to isolate the wireless connection from Member.
It can make the wireless clients (stations) with the same SSID not
accessing for each other.
ssid_num: Choose 1, 2, 3 or 4 to specify SSID1, SSID2, SSID3 or SSID4.
enable: It means to enable such function.
It means to isolate the wireless connection from VPN.
ssid_num: Choose 1, 2, 3 or 4 to specify SSID1, SSID2, SSID3 or SSID4.
enable: It means to enable such function.
It means to display the status of wireless isolation.
e
l e
wl dual config ratectl 1 1 25 25
0: disable and 1:enable
0: disable and 1:enable.
0: disable and 1:enable.
)
911
