Username
Password
Polling Interval
After finishing all the settings here, please click OK to save the configuration.
V V I I I I - - 5 5 - - 1 1 - - 2 2
Central VPN management is operated through IPsec VPN connection.
Available settings are explained as follows:
Item
IPsec Mode
Security Method
Encryption Type
Local Subnet
After finishing all the settings here, please click OK to save the configuration.
534
Type a username which will be used by any CPE trying to
connect to Vigor router.
Type the password for the user.
Type the time value (unit is second). The range is from 60 ~
86400.
I I P P s s e e c c V V P P N N S S e e t t t t i i n n g g s s
Description
Choose Aggressive or Main as the IPsec Mode.
Choose one of the following methods (AH or ESP) for the
security of data transmission. For example, choose AH to
specify the IPsec protocol for the Authentication Header
protocol. The data will be authenticated but not be
encrypted.
Choose one of the selections as the encryption type.
Type the IP address and subnet mask of local host.
Vigor2926 Series User's Guide
