T e l n e t C o m m
T e l n e t C o m m
S y n t a x
S y n t a x
voip dsp countrytone [channel] [value]
voip dsp dialtonepwr [channel] [AbsoluteValue]
voip dsp EchoCanceller [type] [w_size] [nlp]
voip dsp cidtype [channel] [value]
voip dsp micgain [channel] [value/(1~10)]
voip dsp spkgain [channel] [value/(1~10)]
voip dsp jitterBuffer [port] [mode] [value]
voip dsp dtmfDetset [nLevel] [nTwist]
voip dsp dtmftonepwr [Level]
voip dsp cwtonepwr [ch] [value]
voip dsp pstnringfxs [1|2] [on|off]
voip dsp relaydbounce [on|off]
voip dsp setRingPat [ring_pattern_index] [patten_num]
voip dsp setDtmfCidlevel –l [value]
voip dsp setDtmfCidlevel –h [value]
voip dsp setDtmfCidlevel –r 0
voip dsp cidplusdigit [1/0] [channel] [value]
S y n t a x
S y n t a x
Parameter
voip dsp countrytone
[channel] [value]
voip dsp dialtonepwr
channel
AbsoluteValue
voip dsp EchoCanceler
type
Vigor2926 Series User's Guide
a n d : v o i p d s p
a n d : v o i p d s p
D e s c r i p t i o n
D e s c r i p t i o n
Description
This command allows users to set the region for the tone settings.
Different regions usually need different tone settings.
Channel – 1 or 2.
Value – displayed as follows:
[2] UK, [3] USA, [4] Denmark, [5] Italy, [6] Germany,
[7] Netherlands, [8] Portugal, [9] Sweden, [10] Australia,
[11] Slovenia, [12] Czech, [13] Slovakia, [14] Hungary,
[15] Switzerland , [16] France , [17] Malta
This setting is used to adjust the loudness of the dial tone. The
smaller the number is, the louder the dial tone is. It is
recommended for you to use the default setting.
Channel - Available channel number: 1 – 2
AbsoluteValue - In -1 dB increments, with 1 corresponding to 6 dBm.
Range - 1 to 30
This command is used to set the type of echo reduction.
0 - Disable the LEC processing.
1 - Cancel using the fixed window.
2 - Cancel using the fixed and moving window.
3 - Cancel using fixed window + Echo Suppressor.
